Stainless Steel Water Tank Truck 6X4 Water Tank Truck For Sale

Vehicle parameters

Vehicle Model

YH5258GSSE

Vehicle Brand

Overall dimensions

9800X2480X2850mm

Curb weight

9105KG

Tank dimensions

6980X2300X1500mm

Tank volume

20000L

Chassis parameters

Chassis model

EQ1258KB3GJ

Chassis brand

DONGFENG

Overall dimensions

9565x2480x2850mm

Wheel base

4350+1300mm

Front/rear wheel track

1940/1860/1860mm

Front/rear suspension

1245/2670mm

Approach/departure angle

28/15°

Maximum speed

85km/h

Chassis Manufacturer

Dongfeng Motor Corporation

Cab

Configuration

A row and a half deluxe cab(with sleeping berth),allowable 3 passengers

Color

Red, other color is optional

Engine

Model

B210 33

Emission

Euro 3

Type

6 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine

Rated power

210hp,rated power speed 2500rpm

Displacement

5900ml

Max. torque

700N.m

Bore x stroke

102x120mm

Manufacturer

Dongfeng Cummins Engine Co., Ltd.

Tire

Size

10.00R20 nylon tire

Number

10+1

Frame

280X80X(7+5)mm

Fuel tank

200L,steel

Front axle

5.0T

Rear axle

10.0T

Drive form

6X4

Rated voltage

24V,DC

Transmissions

Gearbox 8JS118, 8 speed forward 1 reverse.

Steering device

Power assisted steering

Steering wheel

Left hand drive

Selective configuration

Air conditioner, steel wire tire

If there is a slight change in the chassis parameters above, please take the actual product as the standard

Water tank structure parameters

Tank dimensions

6980X2280X1500mm

Tank volume

20000L

Tank material

Carbon steel

Tank thickness

5mm

Nozzle sprinkling width

≥14m

Range of water cannon

≥28m

Suction height

≥7m

Color and Logo

Optional

Standard configuration

Chassis, sub frame, carbon steel water tank, manhole, water pump, front/side/rear spray nozzle, rear working platform, water cannon, fire valve, water valve, filter gauze, water hose, climbing ladder.
