Vibratory Deburring Bowls Finishing Machine
US $750.00-$800.00
Stainless steel pipe electro polishing machine
- Category: Metal Polishing Machine >>>
- Supplier: Foshan YXH Tube Mill & Mould Co. Ltd.
Share on (62586333756):
Product Overview
Description
Detailed Images
Parameter
| Technical data | YP-8 | YP-10 | DYP-10 | YP-8(New) | DYP-8(New) |
| Model(Unit) | 8 | 8 | 10 | 8 | 8 |
| Working range | 12.7—Φ63 | 12.7—Φ63 | 50—Φ113 | 12.7—Φ63 | 50—Φ113 |
| Polishing speed | 2~30M/NIM | 2~30M/NIM | 2~30M/NIM | 2~40M/NIM | 2~40M/NIM |
| Rated power(KW) | 5.5KW=4,4KW=4 | 5.5KW=5,4KW=5 | All 5.5KW | All 7.5KW | All 11KW |
| Motor power(KW) | 3kw VFD | 3kw VFD | 4kw VFD | 4kw VFD | 4kw CVT |
| Total power(KW) | 41 | 50.5 | 59 | 64 | 92 |
| Voltage(V) | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ | 380V/50HZ |
| Machine size (L*W*H MM) | 5640*1270*1350 | 7040*1270*1350 | 7040*1270*1350 | 7940*1270*1350 | 7940*1270*1350 |
Packaging & Shipping
We use steel wire and wooden frame to fix the Automatic pipe polishing machine;
In addition, used shockproof film to protect the main motors.
We use the container to deliver goods to our customer.
Generally speaking, we start at FOSHAN port, but we also can start at other port according to customer's need.
Advantages
Contact Us
 | Suanna Manager
| |
| Tel: | +86 757 81208127 | |
| Cell/WhatsApp: | +86 13825598889 | |
| Moblie: | +86 13318323628 | |
| Wechat: | 2211600292 | |
| Skype: | suanna1320 | |
