Huaguang Best Quality PS Plate, Conventional Plate, Offset plate

Huaguang Best Quality PS Plate, Conventional Plate, Offset Plate

Huaguang Best Quality Offset Printing PS Plate Type YP-II Technical Specifications

Plate type

Conventional positive plate

Substrate

Electro­-chemically grained and anodized lithographic aluminum.

Gauge

0.15/0.20/ 0.25/ 0.30/0.40(mm)

Maximum width

1320mm

Spectral sensitivity

350­-420nm

Safelight

UV filtered or Yellow

Sensitivity

80-100mj/cm²

Color change

Blue ­Green to Green after exposed

Developer

Huaguang PD developer (concentrated solution), 1 liter can process 15 sqm. Recommended dilution ratio: 1:4 (machine process), 1:5(manual process)

Dot reproduction

2%­-98% in 200 lines/inch

Packaging

0.15 mm 100 pieces/box

0.25/0.30 mm 50 pieces/box if length<1030mm;

                       30 pieces/box if length≥1030mm;

                       25 pieces/box if the area>1m²

Shelf life

18 months when stored in a light­-free area away from excessive cold, heat and high humidity

Run length

Above100,000 (Actual run length may vary according to press, ink and stock conditions.)
