vertical silicone rubber hose extruder

Product Overview

Description

Vertical silicone rubber extruder

Model XJWP65×16D cold-feeding rubber extruder



Outlet direction:                         Right in and left out facing the device



Central height of extruder:                 1050mm±20mm



L/D                                     16:1



Screw diameter                          65mm



Max. screw speed (r/min)                   55



Capacity(kg)                             150kg/h



Feeding mode:                           Active feeding with side roller



Speed adjustment mode:                   Variable frequency speed regulation



Speed adjustment panel:                     DELTA Inverter



Main motor power:                           22kw



Pressure control:                     With pressure sensor, pressure protection value adjustment rage:                           0-35MPA



Single drive:                             One set



Cooling water                            0.15-2KG/ Cm2



power                                   AC380V50HZ



Hard tooth-faced reductor                   ZLYJ200-20-I





External dimensions                 2700(L) ×1000(W) ×1520(H)mm
