Products Description


222
With the development of modern mechanical processing industry, the requirements of cutting quality and precision are constantly improving, and the requirements of improving production efficiency, reducing production cost and high intelligent automatic cutting function are also improving. The development of CNC cutting machine must meet the requirements of modern mechanical processing industry.





1. Used for curtain wall and window of aluminum accurate cutting ,also for UPVC profile.
2. Single head any angle cutting saw with the carbide saw blade, which make sure the high speed and accurate cutting.
3. This machine can be installed the size positioning frame 3m, also can add digital display device according to your requirement, thus can make the locating size more accurate.





4. The workbench rotating between (-15 °)~90°~(+15°). after the plate retrocession, the workbench can be 0°positioning, then raise and fix the saw blade thus this machine can be used as Routing saw.
5. Auto-opening shield makes the operation more safely.
6. Roller conveyors, Saw blades, Digital display devices, Size positioning frame is optional.




Specification


Power supply
380V 50Hz,three phase
Motor power
2.2 Kw
Air pressure
0.5~0.8MPa
Air consumption
10L/min
Motor rotation speed
2840r/min
Blade feeding speed
stepless timing 0~3m/min
Cutting angle
(-15°) ~90°~(+15°)
Cutting profile surface plane
≤0.10mm
Cutting angle tolerance
Ra12.5 μm
Cutting width
243mm,90°MAX
Cutting height
120mm,90°,MAX
Saw blade diameter
400mm
Overall dimension
850*1100*1500mm
Weight
300Kg
