12 15 19 21 дюймовая промышленная панель ПК Передняя планшет сенсорный экран ip65 водонепроницаемый ударопрочный linux
606,00 $ - 678,00 $
Супер Мини ПК цп пк безвентиляторный мини core i7 intel nuc Сервер компьютер встроенный
- Категория: Промышленные компьютерные и аксессуары >>>
- Поставщик: Shenzhen Geshem Technology Co. Limited
Сохранить в закладки 1600203097632:
Описание и отзывы
Характеристики
Related Products
Product Description
Products Specification
Performance | ||
Chipset | Intel Celeron J1900/3865U/3855U/Core i3/i5/i7 | |
Memory | 2GB DDR3, up to 8GB; Intel3865U/3855U 2GB DDR4 up to 8GB; Core 2GB DDR4 up to 16GB | |
Storage | 64GB SSD, up to 512GB Msata MLC SSD | |
Hardware Monitor | Monitors voltage, CPU, TEMP | |
Watchdog | 0-255 sec by software | |
OS | Windows 10 and linux OS (J1900 also support windows 7) | |
Power Supply | 9-24V DC IN or 9-36V DC IN optional; 12V5A power adapter is standard | |
I/O | ||
USB | J1900: 5*USB2.0+1*USB3.0; Core/3865U/3855U: 4*USB3.0+2*USB2.0 | |
COM | 6*RS232 (1 or 2*RS485/RS422 optional) | |
Ethernet | 2*RJ45 GbE 1000M | |
Audio | 1*Line out+1*Mic | |
Display | 1*VGA+1*HDMI | |
Mini PCIe | 1*MiniPCIe for WiFI/BT/3G/4G option | |
GPIO | 1*4in/4out optional ( Ocupy one COM port) | |
Environmental | ||
Anti-Vibration | 5-19Hz/1.0mm amplitude;19-200Hz/1.0g, acceleration | |
Anti-shock | 10g acceleration, 11ms duration | |
IP level | Front panel IP65(optional) | |
Reliability | MTBF≥5000h; MTTR≤0.5h | |
Working Temp.: | -20℃--70℃ with air flow | |
Strage Temp.: | -30℃ --80℃ | |
Working Humidity | 95% @40℃, non-condensing | |
Mechanical | ||
Dimension | 211.5mm(L)*200mm(W)*67mm(H) | |
Installation | Put on desk or Stand for embedded installation; DIN Rail installation optional | |
Material | Fanless design, High-strength and elegant Al-alloy casing | |
Weight | 2.6kg/4.0kg(NET/Gross) | |
Color | Black | |
Certificate | CE/FCC/RoHs certificate | |
Warranty | 1 year warranty; extended warranty is available too. | |
Order Information
Ordering information for industrial embedded fanless box pc, welcome to inquire!
Product Application
Product photo
Company Profile
FAQ
Q What’s your lead time?
Depends on order qty, usually 3-5 working days for sample order.
Q: Are you manufacturer with your own factory or trading company?
A: We are manufacturer with our own factory located in Shenzhen.We produce industrial panel pc from 7” to 21”, embedded box pc,and rugged tablets. If you are available, welcome to visit us.
Q: How can I get some samples?
A: We are honored to offer you samples, please contact us directly.
Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality controlling from beginning to the end. We have good
supplier-chain management. Our factory has gained CE, FCC, ROHS,IP67 certifications.
Q: Are you the original manufacturer of industrial pc and rugged tablet?
A: Yes,We are. Every product includes motherboard design, function modules and mould of casing are entirely made by Geshem itself. We also have some agents who sell our products in China and abroad.
Depends on order qty, usually 3-5 working days for sample order.
Q: Are you manufacturer with your own factory or trading company?
A: We are manufacturer with our own factory located in Shenzhen.We produce industrial panel pc from 7” to 21”, embedded box pc,and rugged tablets. If you are available, welcome to visit us.
Q: How can I get some samples?
A: We are honored to offer you samples, please contact us directly.
Q: How does your factory do regarding quality control?
A: Quality is priority. We always attach great importance to quality controlling from beginning to the end. We have good
supplier-chain management. Our factory has gained CE, FCC, ROHS,IP67 certifications.
Q: Are you the original manufacturer of industrial pc and rugged tablet?
A: Yes,We are. Every product includes motherboard design, function modules and mould of casing are entirely made by Geshem itself. We also have some agents who sell our products in China and abroad.
Q:What kind of services can you provide?
A: We have two services models, one is OEM/ODM service,which is with customer’s brand based on our standard products, the other isprovide customization service according to the customer’s individual demands, which are including appearance design, structure design, mold development, soft & hardware development, technical support and etc.Many famous brand are our customers such as DELTA in China.
Q: What are your product lines?
A: We have been engaged in the R&D and production of industrial PC and rugged tablets in the industrial field since 2008. Up till now, we have established Beijing, Shanghai and Chengdu branch offices in China, and also one branch office in Dusseldorf in Germany. And we also some good foreign distributors.
Q: How about your after sale?
A: 1 year warranty ensured from the date of delivery. Free repairing is available for functional problems of non-artificial
damage, otherwise that will be charged. Once you have after-sales need,our FAE employees will provide
remote technical support & send maintenance materials first, FAE employees can also be sent to the customer’s place to repair depending on the situation, or customer can directly send the damaged products back to China or our Germany office, they will be repaired and send it out quickly.
A: We have two services models, one is OEM/ODM service,which is with customer’s brand based on our standard products, the other isprovide customization service according to the customer’s individual demands, which are including appearance design, structure design, mold development, soft & hardware development, technical support and etc.Many famous brand are our customers such as DELTA in China.
Q: What are your product lines?
A: We have been engaged in the R&D and production of industrial PC and rugged tablets in the industrial field since 2008. Up till now, we have established Beijing, Shanghai and Chengdu branch offices in China, and also one branch office in Dusseldorf in Germany. And we also some good foreign distributors.
Q: How about your after sale?
A: 1 year warranty ensured from the date of delivery. Free repairing is available for functional problems of non-artificial
damage, otherwise that will be charged. Once you have after-sales need,our FAE employees will provide
remote technical support & send maintenance materials first, FAE employees can also be sent to the customer’s place to repair depending on the situation, or customer can directly send the damaged products back to China or our Germany office, they will be repaired and send it out quickly.
