Удобрения химические материалы 304 SS 10 кг 15 20 25 50 пластиковые небольшие пакеты автоматическая упаковочная машина

 Our company Liyang Zeji Machinery Co., Ltd. is a professional manufacturer focus on: hammer mill, mixer, feed/wood pellet machine, cooler, crumbler, screener, extruder, dryer, packing machine, liquid adding machine, conveyors and spare parts: wood chipper fly-knives, hammer mill blades/screen, ring die, roller and other pellet machines’ spare parts.
For machines, we have own laser cutter, CNC machining center, welding machines. For ring die, we have own auto gun-drilling machines (12 sets), auto counter-sinking machines, auto lathing machines, vacuum heat treatment machines.
We insist on high quality and competitive price, looking for long term business and win-win.

DCS-ZW packaging machine is an electromechanical integration product suitable for precise and rapid weighing and bagging of pellets. It is widely used in food, feed, chemical and other fields.

This product has good adaptability to the working environment. The weighing range is wide, and any weighing setting can be made in the range of 20kg~50kg (just consider the size of the opening of the bag). Weighing control uses current advanced software and hardware technology to make the product work more stably and reliably. The instrument has a good man-machine dialogue function, which is convenient for the operator to modify relevant parameters to make the packaging work faster and more accurate.

Model selection:

A, System parameters

a,Working power

Power section: AC380V 50Hz(3phase)

Control section: AC220V 50Hz

b,Equipment power: 3KW

c,Air pressure: 0.4~0.6MPa , need dry and clean

d,Operating temperature: 0℃~40℃

e,Relative humidity:<90%, no condensation.

f,Warm-up time before running:>15 min

B, Technical indicators

a,Static accuracy: <±0. 1%F.S

b,Dynamic accuracy: <±0. 2% F.S

c, Packing speed: 5-7bag/min (40Kg/bag, refer to pelelts' volume-weight is about 1.5, and moisture content less than 10%.)

d,If there is no special agreement, the material is carbon steel, and the contact part of the material is 304 stainless steel.

Main Feature

The single-bucket packaging machine is composed of a centralized control box A, feeder machine B, weighing machine C, a bag-holding machine D, and so on.

A. The centralized control box consists of the following parts:

a .Intelligent weighing control instrument (M04), which is the control core of the packing machine;

b .Control switch, DC24V power supply

c .Terminals

d. The control panel also included various control switches and indicator lights

B. Feeder machine consists of the following parts:

  a. Three-speed self-flow feeding machine (arc door, three-stroke cylinder), 1set

C. Weighing machine consists of the following parts:

a. Weighing sensor, 1pc

b. Weighing hopper, 1pc

D. Bag-holding machine consists of the following parts:

    a. Bag-holding cylinder, 1pc

    b. Bag clipper, 1set

Darren

Sales Engineer

------------------------------------------------------------------------------------------------------------------------

Liyang Zeji Machinery Co., Ltd.

Office: Building 5, Pingfeng Garden, Guxian Street, Liyang City, Jiangsu Province, China

Factory: No.1, Tengfei Road, Liyang City, Jiangsu Province, China

WhatsApp/Wechat/Skype: 0086-13961174817

Web: machines:  www.lyzjm.com,  Spare parts: www.ring-die.com
