Высокое давление чугунный усилитель DL вертикальный многоступенчатый центробежный водяной насос
74 943,69 ₽
Высокоэффективный DL/CDL4 19 вертикальный не самовсасывающий многоступенчатый центробежный насос приводимый в действие стандартным электродвигателем
- Категория: >>>
- Поставщик: Luoyang Pioneer Anticorrosion Equipment Co. Ltd.
Сохранить в закладки 1601200956562:
Описание и отзывы
Характеристики
Product Description
Application
Pump
* Altitude: up to 1000m
Pump motor
CDL/CDLF pump are multi-functional products. It can be used to convey various medium from tap water to industrial liquid at different temperature and with different flow rate and pressure. CDL type is applicable to conveying non- corrosive liquid, while CDLF is suitable for slightly corrosive liquid.
* Watersupply: water filter and transport in waterworks, boosting of main pipeline, boosting in high rise building.
* Industrial boosting: process flow water system, cleaning system, high pressure washing system, fire fighting system.
* Industrial liquid conveying: Cooling and air-conditioning system, boilerwater supply and condensing system, machine-associated purpose, acid sand alkali.
* Watertreatment: ultra filtration system, RO system, distillation system, separator,swimming pool.
* Irrigation: Farmland irrigation, dripping irrigation.
Pump
CDL/CDLF pump are vertical non-self priming multistage centrifugal pump, which is driven by a standard electric motor.The motor
output shaft directly connects with the pump shaft through a coupling. The pressure resistant cylinder and flow passage components
are fixed between pump head and in-and outlet section with tie-bar bolts. The inlet and outlet are located at the pump bottom at the same plane. This kind of pump can be equipped with an intelligent protector to effectively prevent it from dry-running,out-of-phase and overload.
Operation conditions
* Thin,clean,non-flammable and non-explosive liquid containing no solid granule sand fibers.
* Liquid temperature:Normal temperature, High temperature
* Ambient temperature:up to+40°C* Altitude: up to 1000m
Pump motor
* Totall-enclosed fan-cooled two-pole standard motor
* Protection class : IP55
* Insulation class:F
* Standard voltage:50Hz:lx220-230/240V 3x200-200/346-380V 3x220-240/380-415V 3x380-415V
Details Images
Specification
item | value |
Warranty | 1 year |
Customized support | OEM, ODM, OBM |
Brand Name | PIONEER |
Model Number | CDL4-19 |
Place of Origin | Jiangsu,China |
Application | Automotive Industry, Biofuel Industry, Developing World Water Solutions, Drinking water treatment, Food and Beverage Industry, Industrial Utilities, Metal and Equipment Manufacturers, Mining industry, Pharmaceutical industry, Raw Water Intake, Wastewater Transport and Flood Control, wastewater treatment, Water Distribution, Water Treatment Solutions |
Horsepower | 5.5hp |
Power Source | Electric |
Pressure | 18.3bar |
Structure | Multistage Pump |
Voltage | 380/400/440V |
Power | 4KW |
motor | IP55 |
Certification | ce |
Rotate speed | 2900 RPM |
Certifications
Packing & Delivery
Plywood case for safety sea shipping
Company Profile
Has been more than 30 years since set up, Luoyang Pioneer Anti corrosion Equipment Co.,Ltd. ls a top leader in manufacturing anti corrosion equipment,pipes and valves inland.Located in the high-developing area of Luoyang Economic Development zone,the company occupies area more than 32800m³.With modern workshops and facilities, perfect quality control system and advanced inspect method, and well-educated staffs that can undertake a full set of anti corrosion equipment of research and development,production and Installment.
Recent years,We have imported advanced foreign technology and high-tech material,Continuous technological innovation, we have successfully supplied high quality products and services for the major Engineering project of nation, such as steel cold roll Acid-wash,acid purification，chemical-industry ionicmembrance caustic soda, phosphor fertlizer; environmental protection sewage treatment and so on,which not only substitute the import, settle the exact for these engineerings, but also saved great foreign exchange, that gain considerable economic and social benefit.The main products of the company can be divided into two types:
1.Full plastic type: PTFE, PVDF,PPH, RPP, PE80,PE100, UHMWPE,UPVC and CPVC full plastic valve,pipe fitting，strainer，board material, filing ring and equipments(Tanks,Purifying Tower Ventilator)series.
2.Steel lining type: PTFE,PVDF，FEP, PEA, PPH,RPP, PO,PE,UHMWPE lining, PU valve， pipe， pipe fitting,equipment，PTFE ripple compensator, and tube, widely used, in the fields of steel, metallurgy, petroleum,chemical industry, fertilizer，dye,pharmacy，electric power，environmental protection sewage treatment,mining industry. Has the advantages of structure innovation，unique craft work，wide temperature adaption,long service life and high benefit,the products is the ideal Anti corrosion engineering material that well favored by the customers and developed its unique outlet in market.
Customer as fundamental, to win the market with credit. Through many years, on the base of strengthening enterprise management. All products in Pioneer have passed the national security (TS) and national industrial product production license certification, the certification of IS09001: 2015 International quality system certification. IS014001 : 2015 Environment management system certification. Continually improve the quality of products and service, was named the titles as "Luoyang city pump valve industrial association vice chairman unit", "National level Spark enterprises","State Torch Program Enterprises", "AA+ degree credit enterprise", "keep the contact and credit "advanced unit, "City level technology center enterprise "，"high-tech enterprise", "key enterprise in Luoyang".
FAQ
1. who are we?
We are based in Henan, China, start from 2019,sell to Domestic Market(20.00%),Southeast Asia(20.00%),Eastern Asia(10.00%),Mid East(10.00%),South America(10.00%),Northern Europe(10.00%),Africa(5.00%),South Asia(5.00%),North America(5.00%),Central America(5.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
centrifugal pump,industrial valve,PTFE lined pipe,chemical pump,Plastic pipe
4. why should you buy from us not from other suppliers?
Luoyang Pioneer Anticorrosion is specialized in the manufacturing of international quality anti corrosion pumps,valves,pipes and fittings. The products are widely used for scrubbing, steel pickling, electroplating, paints, dye stuffs, chlor alkali,
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU,DAF；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Russian
We are based in Henan, China, start from 2019,sell to Domestic Market(20.00%),Southeast Asia(20.00%),Eastern Asia(10.00%),Mid East(10.00%),South America(10.00%),Northern Europe(10.00%),Africa(5.00%),South Asia(5.00%),North America(5.00%),Central America(5.00%). There are total about 5-10 people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
centrifugal pump,industrial valve,PTFE lined pipe,chemical pump,Plastic pipe
4. why should you buy from us not from other suppliers?
Luoyang Pioneer Anticorrosion is specialized in the manufacturing of international quality anti corrosion pumps,valves,pipes and fittings. The products are widely used for scrubbing, steel pickling, electroplating, paints, dye stuffs, chlor alkali,
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,DDP,DDU,DAF；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese,Russian
