2024 Evangel 4 Тонный водогрейный котел WNS4 1.25 YQ на природном газе итальянская брендовая горелка Riello для Азии
- Категория: >>>
- Поставщик: Evangel Industrial (shanghai) Co. Ltd.
Сохранить в закладки 1601206769512:
Описание и отзывы
Характеристики
Contact Way
Sales Manager: Frank Xie
Whatsapp/Mobile Phone/Wechat: +86 18321199733
Whatsapp/Mobile Phone/Wechat: +86 18321199733
Email: frank@evangelchina.com
I'm Frank and I will always be frank.
Pls feel free to contact me if you need more information. Looking forward to your news!
Specification
Model | Ratd SteamCapacity | Nitrogen oxides | Design Fuel | Max Transport Weight | Max Transport Dimension (LxWxH) |
unit | (t/h) | (mg/m3) | (kg) | (mm) | |
WNS1-1.25-YQ | 1 | 18-30 | Natural Gas, Light oil, Heavy oil, Etc. | 5500 | 3300*1800*2000 |
WNS2-1.25-YQ | 2 | 18-30 | 7500 | 4000*2000*2950 | |
WNS3-1.25-YQ | 3 | 18-30 | 8000 | 4350*2200*2600 | |
WNS4-1.25-YQ | 4 | 18-30 | 10000 | 4800*2300*2800 | |
WNS6-1.25-YQ | 6 | 18-30 | 14000 | 5400*2500*2950 | |
WNS8-1.25-YQ | 8 | 18-30 | 20226 | 6955*2480*2986 | |
WNS10-1.25-YQ | 10 | 18-30 | 21500 | 6300*2700*3200 | |
WNS12-1.25-YQ | 12 | 18-30 | 23000 | 6700*2700*3200 | |
WNS15-1.25-YQ | 15 | 18-30 | 27700 | 7365*3200*3508 | |
WNS20-1.25-YQ | 20 | 18-30 | 30000 | 8050*3750*3960 |
Products Description
Chinese Official Factory Gas Boiler Low Nitrogen Gas Steam Hot Water Boiler Three Return WNS Gas Steam Boiler
WNS series gas/oil fired steam boiler is three-pass full wet back structure, adopting large furnace and thick smoke pipe to increase the heat absorption of the furnace and effectively save energy and reduce consumption. The threaded pipe and corrugated furnace greatly enhance the heat transfer effect and greatly save fuel consumption. The main structure includes: boiler shell, ripple furnace, reversal chamber, thread smoke tube, etc. The burner brand can be chosen according to user’ s requirement. WNS series gas/oil fired steam boiler is designed and optimized to produce low pressure steam or hot water with rated evaporation capacity from 1 to 20 ton/hour and rated pressure from 0.7 to 1.6MPa. The design heat efficiency is up to 95%.
our boiler is 3 pass design, to make the flue gas goes 3 times inside, 1st to reduce the exhausted flue gas temperature for environment friendly, 2nd great use the heat of the flue gas compared to 2-pass or 1 pass boiler, it’s much higher efficiency and save fuels how does the fire flow inside the boiler ? Fire from burner go into corrugated furnace, smoke goes to pass 2 through reversal chamber, then go to pass 3 through front smoke box, then go to economizer then go to chimney to the atmosphere.
Details Images
Recommend Products
Our Advantages
Company Profile
EVANGEL Automobile Sales (Shanghai) Co., Ltd. is a top package equipment solution provider in Shangha China,
especially for construction machinery, heavy industrial equipment and vehicle. We represent high quality China machinery brands such as XCMG, SANY, ZOOMLION, LIUGONG, LONKING, SEM, SDLG, SHANTUI, YTO, SINOMACH, SINOTRUK, SHACMAN, BEIBEN etc., and also export famous international brands such as CATERPILLAR and HYUNDAI. We are always committed to offer our customers high quality products with reliable performance, competitive price and comprehensive services, to ensure every engineering project to be run smoothly on schedule.
With over eleven years' experience in the field of engineering industry and accompanying to fulfill strictly ISO 9001:2008 standard, EVANGEL had established and have been consistently keeping good business relationship with many general contractors, civil engineering firms and construction companies throughout the world. We participated as package equipment provider previously include airport projects in Africa, power plant projects in Middle East, dredging projects in South America, highway projects in Oceania, rural and municipal road projects in Southeast Asia, and we are still achieving more and more projects at present.
To provide reliable products with quick delivery time, to make prompt reaction for spare parts and after-sales services, to visit the users field regularly for local training and maintenance, EVANGEL has been often praised by our customers and has taken great reputation as a trustworthy project partner.
EVANGEL believe in combining our own achievement together with our customer benefits. Open communication, effective planning and elaborative preparation always commit us to execute and deliver our promises for our customers all over the world.
1. who are we?
We are based in Shanghai, China, start from 2014,sell to South America(30.00%),Africa(30.00%), Southeast Asia (15.00%), Oceania(10.00%),Mid East(10.00%), SouthAsia (1.00%), WesternEurope 1.00%), SouthernEurope (1.00%), Northern Europe(1.00%), Eastern Europe(1.00%). There are total about 200-250 people in our office.
We are based in Shanghai, China, start from 2014,sell to South America(30.00%),Africa(30.00%), Southeast Asia (15.00%), Oceania(10.00%),Mid East(10.00%), SouthAsia (1.00%), WesternEurope 1.00%), SouthernEurope (1.00%), Northern Europe(1.00%), Eastern Europe(1.00%). There are total about 200-250 people in our office.
2. why should you buy from us not from other suppliers?
(i) Professional Experience in Construction Machinery;
(i) Professional Experience in Construction Machinery;
(ii) International Sales Team;
(iii) Long Term Dealership from Top China Manufacturers;
(iv) Excellent Logistics Services;
(v) Comprehensive After-sales Service;
(vi) Quality Control.
3. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian.
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian.
