Сборочная печь YX835 с 8 температурной зоной для производственной линии SMT
- Категория: >>>
- Поставщик: Wenzhou Yingxing Import&Export Co. Ltd.
Сохранить в закладки 1601272577346:
Описание и отзывы
Характеристики
Product Description
Introduction
This machine adopts the M-type stainless steel finned heating pipe with corrosion resistance, high temperature resistance, long service life and high heat efficiency. Cooperating with hot air circulation system, the heat storage structure allows the heat to be fully used. The multi-layered heat insulation structure minimizes the loss of heat. The temperature is controlled by PID closed circle, with highly precise temperature control.
Part list
1.Instruction Manual * 1 PC
2.Certification * 1 PC
3.Exhaust Duct * 2 Units
4.Pipe Button * 2 Units
5.Temperature Profile Sensor * 1 Unit
6.Computer, Keyboard, Mouse, Displayer * 1 Unit
The YX835 software was developed by ourselves. The software is available in English. And our software will be updated, as soon as there is an update, the salesman will send new software to your mailbox.
The YX835 machine has one year warranty, lifetime maintenance. We have a professional after-sales team. As long as there is a problem with the machine within one year after purchase, we will repair it for free. If there is a need to replace the accessories, we will send them to your hands for free.(Generally we use TNT/DHL. 3-5 business days to your hands).
This machine adopts the M-type stainless steel finned heating pipe with corrosion resistance, high temperature resistance, long service life and high heat efficiency. Cooperating with hot air circulation system, the heat storage structure allows the heat to be fully used. The multi-layered heat insulation structure minimizes the loss of heat. The temperature is controlled by PID closed circle, with highly precise temperature control.
Part list
1.Instruction Manual * 1 PC
2.Certification * 1 PC
3.Exhaust Duct * 2 Units
4.Pipe Button * 2 Units
5.Temperature Profile Sensor * 1 Unit
6.Computer, Keyboard, Mouse, Displayer * 1 Unit
The YX835 software was developed by ourselves. The software is available in English. And our software will be updated, as soon as there is an update, the salesman will send new software to your mailbox.
The YX835 machine has one year warranty, lifetime maintenance. We have a professional after-sales team. As long as there is a problem with the machine within one year after purchase, we will repair it for free. If there is a need to replace the accessories, we will send them to your hands for free.(Generally we use TNT/DHL. 3-5 business days to your hands).
Model | YX835 |
Heat Zones Number | 8 Zone(Up4+Down4) |
Heat Method | Hot Wind |
Hot Wind Method | Frequency Conversion Air Supply |
Cooling Zones Numbers | Three Natural Air Cooling |
Length of Heating Zones | 1400mm |
Mesh Width | 450mm |
Conveyor Width | 350mm |
Allow PCB Width | Max.350mm |
Allow PCB Length | No Limited |
Allow PCB Height(Mesh) | 50mm |
Allow PCB Height(Conveyor) | 25mm |
The Height of the mesh from ground | 880±20mm |
The Height of the conveyor from ground | 900±20mm |
Transportation Speed | 160-1350mm/min |
Transportation Method | Digital Display Speed Regulation |
Transport Direction of Net Belt | L-R |
Chain Dripping | Timing Automatic Dripping |
Input Power | Three-phase Rive-wire 380V±10％ 50Hz |
Heating UP Time | 15-20 mins |
Time of Passing Through the Machine | 3.5-5.5 mins |
Range of Temperature Control | Indoor Temperature-400 Degrees |
Method of Temperature Control | Touch Screen Comtrol (PID Close-Cycle Calculate Method) |
Starting Power | 15KW |
Working Power | 3KW |
Outline Size | L2720*W820*H1360mm |
Weight | 450KG |
Product Details
Company Information
Exhibition
Certifications
Product packaging
FAQ
Q:How is the training?
A:After buying our machines,your engineers can go to our company or it is so easy to operate the machine according the training video and user manual,the user manual will come with the machine together.
Q:Is it hard to use these machines?
A:After buying our machines,your engineers can go to our company or it is so easy to operate the machine according the training video and user manual,the user manual will come with the machine together.
Q:Is it hard to use these machines?
A:No,not hard at all.For our previous clients,at most 2 days is enough to learn to operate the machines.
Q:Does your machines have quality certificate?
A:All of our machines have passed CE certificate,ISO14001(BCC),ISO9001(IQNET) and have own patent.
Q:The Warranty of the machine?
A:One year,then the parts will be free for the buyer in the warranty.
Q:English version for these machines?
A:Yes
Q:Does your machines have quality certificate?
A:All of our machines have passed CE certificate,ISO14001(BCC),ISO9001(IQNET) and have own patent.
Q:The Warranty of the machine?
A:One year,then the parts will be free for the buyer in the warranty.
Q:English version for these machines?
A:Yes
