2024 новый однофазный изолирующий трансформатор BK 1500 380 В до 220 сухой 1500VA управления
- Категория: >>>
- Поставщик: Anhui Kesidi Electric Co. Ltd.
Сохранить в закладки 1601273177959:
Описание и отзывы
Характеристики
Products Description
BK series control transformers (hereinafter referred to as transformers) are suitable for circuits with voltages up to 500V and frequencies of 50~60Hz. They are usually used as power sources for machine tool control electrical equipment, local lighting, and indicator lights. The BK series machine tool control transformers can be divided into enclosed types based on their structure and vertical types based on their installation methods.
Specification | BK50VA up to 100VA | ||||||
Single-phase input voltage | 220V/380V/400V/415/480V/660V | ||||||
Single -phase output voltage | 6V/12V/24V/36V/110V/220V | ||||||
Working frequency | 50Hz/60Hz | ||||||
Efficiency | ≥ 90% | ||||||
Waveform distortion | No additional waveform distortion | ||||||
Load power factor | 0.9 | ||||||
Electric strength | 2500V/1min without breakdown | ||||||
Insulation resistance | ≥2MΩ | ||||||
Ambient temperature | -5°C~ +40°C | ||||||
Details Images
Model | Product size (CM) | Pcs/Outer Packing | Outer Packing (CM) | Weight (KG) | ||||
B max | D max | E maX | A | C | ||||
(mm) | (mm) | (mm) | (mm) | (mm) | ||||
BK-50VA | 78 | 66 | 90 | 56±0.4 | 48±3 | |||
BK-100VA | 84 | 78 | 93 | 65±0.4 | 62±2.5 | |||
BK-150VA | 102 | 88 | 110 | 76±0.4 | 68±2.5 | |||
BK-200VA | 102 | 95 | 110 | 76±0.4 | 74±3 | |||
BK-250VA | 114 | 110 | 120 | 90±0.4 | 80±3 | |||
BK-300VA | 114 | 120 | 120 | 90±0.4 | 85±3 | |||
BK-400VA | 133 | 100 | 140 | 100±0.4 | 90±3 | |||
BK-500VA | 133 | 110 | 140 | 100±0.4 | 95±3 | |||
BK-700VA | 133 | 120 | 140 | 100±0.4 | 105±3.5 | |||
BK-1000VA | 150 | 140 | 160 | 123±0.4 | 117±3.5 | |||
BK-1500VA | 180 | 170 | 160 | 130±0.4 | 130±3.5 | |||
BK-2000VA | 180 | 190 | 190 | 130±0.4 | 150±3.5 | |||
BK-3000VA | 195 | 210 | 200 | 140±0.4 | 173±3.5 | |||
BK-4000VA | 240 | 210 | 240 | 178 | 162 | |||
BK-5000VA | 240 | 230 | 240 | 178 | 172 | |||
BK-8000VA | 300 | 300 | 320 | 250 | 170 | |||
BK-10KVA | 300 | 330 | 320 | 250 | 160 | |||
BK-15KVA | 300 | 360 | 320 | 250 | 200 | |||
BK-20KVA | 360 | 360 | 380 | 300 | 210 | |||
Company Profile
Anhui Kesidi Electric Co.,Ltd. The company mainly deals with the production of voltage regulators, non-contact voltage regulators,purification regulators, transformers, regulators, inverters, UPS uninterruptible power supply, solar energy and other products.
Now the company has modern calibration equipment, professional technology and operation team, for product quality provides areliable guarantee, more perfect after-sales service guarantee system as well as always online manager consultant to solve problems for you at any time. The company endeavors to advocate science and technology as the navigation, quality-oriented,integrity management. Our aim is to develop and innovate power applications in an all-round way to achieve high productivity, high efficiency and energy saving in production automation, reliability and safety. Looking to the future, all the staff of the company will be in “Harmony, Humble, Learning, Innovation” under the guidance of the corporate culture, continue to provide customers with professional quality products and quality service, and share the fruits of development with customers. Strive for excellence and innovation to grasp the development, safety and peace of mind for customers.
Now the company has modern calibration equipment, professional technology and operation team, for product quality provides areliable guarantee, more perfect after-sales service guarantee system as well as always online manager consultant to solve problems for you at any time. The company endeavors to advocate science and technology as the navigation, quality-oriented,integrity management. Our aim is to develop and innovate power applications in an all-round way to achieve high productivity, high efficiency and energy saving in production automation, reliability and safety. Looking to the future, all the staff of the company will be in “Harmony, Humble, Learning, Innovation” under the guidance of the corporate culture, continue to provide customers with professional quality products and quality service, and share the fruits of development with customers. Strive for excellence and innovation to grasp the development, safety and peace of mind for customers.
FAQ
Q1: What are the warranty terms?
A1: Within one year from the date of sale, if there is any problem with the accessories, you only need to provide the photos of the damaged accessories and we will provide the accessories free of charge. Depending on the number of products, we will provide the easily damaged accessories free of charge. We can also provide technical support if you need.
Q2: Do you support customisation?
A2: Yes, no problem, but order quantity requirement
Q3: Support OEM/ODM?
A3: Yes! Our products can be customised. We design and produce all kinds of automatic voltage regulators/stabilisers according to customers' specific requirements.
Q4: What is the minimum order quantity?
A4: For small capacity products (automatic voltage regulator/stabiliser) with default configuration, it is 10 sets. For large capacity products, it is 1 set.
Q5: What kind of certificates do you have?
A5: CE, ISO9001 and SGS.
Q6: What are the payment terms?
A6: L/C, T/T, D/P, D/A, Western Union and MoneyGram (for small payments)
A1: Within one year from the date of sale, if there is any problem with the accessories, you only need to provide the photos of the damaged accessories and we will provide the accessories free of charge. Depending on the number of products, we will provide the easily damaged accessories free of charge. We can also provide technical support if you need.
Q2: Do you support customisation?
A2: Yes, no problem, but order quantity requirement
Q3: Support OEM/ODM?
A3: Yes! Our products can be customised. We design and produce all kinds of automatic voltage regulators/stabilisers according to customers' specific requirements.
Q4: What is the minimum order quantity?
A4: For small capacity products (automatic voltage regulator/stabiliser) with default configuration, it is 10 sets. For large capacity products, it is 1 set.
Q5: What kind of certificates do you have?
A5: CE, ISO9001 and SGS.
Q6: What are the payment terms?
A6: L/C, T/T, D/P, D/A, Western Union and MoneyGram (for small payments)
