Смарт серверная стойка 1U 6 Ланс I350 * 4 материнская плата с электрическим интерфейсом B660 расширяемый PCIE сетевой ПК промышленный компьютер 19 дюймов

Смарт серверная стойка 1U 6 Ланс I350 * 4 материнская плата с электрическим интерфейсом B660 расширяемый PCIE сетевой ПК промышленный компьютер 19 дюймов

Категория: >>>
Поставщик: Dongguan Mini Tree Computer Manufacturing Co. Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Specification

Model	1U6L-B660 12th Gen Network Security Server
Color	Black
CPU TDP	I3 60W,i5-i7 60W,i9 125W
Chipset	Intel B660 12th LGA1700 Core i3/i5/i7/i9 processors
Memory	2*DDR4 SO-DIMM (Up to 64GB)
Storage	1M.2 NVME 2280; 4SATA (1*2.5"/ 3.5"HDD/SSD Bracket)
Graphics	Intel UHD Graphics 730/770
Display Port	1VGA 1HDMI(Optional),Please contact customer service if you need .
Front I/O	1Power/HDD indicator light, 1 COM (support Console), 2 USB3.0,6intel i226V 2.5G Lan
Rear I/O	1 Power Button, 1*VGA , 1 AC power
Expansion Slot	1*PCIE X16 (Not available if SFP is selected)
	1*PCIe x4 FPC(Need FPC Cable)
	1 M.2 for /5G /1*M.2 for WIFI
	1*Mini PCIe for 4G
Network Card	6*Intel i226 2.5G Ethernet
Input Power	Mean Well LRS-350-24 Input: 100-240V~1.0A Output: 24V 6.25A
Other Function	Watchdog,PXE, Wake on LAN, Auto power on, Timing boot
Work Temp	0℃～+50℃, surface air flow
Work Humidity	5% ~ 95% non-condensing state
Dimension	44025745mm(Without rack ear)
Weight	6.5 kg (barebone)
Application	Firewall, VPN, network server, network security, router and etc,.

Intel Core I3-12100 (4 Core 8 Threads, 3.3 Ghz, Turbo Frequency 4.3 Ghz)

Intel Core I5-12400 (6 Core 12 Threads, 2.5 Ghz, Turbo Frequency 4.4 Ghz)

Intel Core I7-12700 (12 Core 20 Threads, 2.10 Ghz, Turbo Frequency 4.9 Ghz)

Intel Core i9 12900K(16 Core 24 Threads,3.2Ghz. Turbo frequency 5.0GHz）

Product Description

Company Profile

Packing&Shipping

What's in the package？
1xMini PC
1xPower supply
1xPower cable ( we ship correct power plug base on buyer's address )
1xHDMI cable
1xSATA power&data cables

Company Introduction

Dongguan Mini Tree Computer Manufacturing Co., Ltd was founded in 2016 as a mini computer developer and wholesaler,Which focus on mini pc ,laptop and industrial computer's producing and selling. There are 20 professional international sales person , most of them has 3 to 10 years international sales experience; 8 technical support team has 10 years computer support experience.

The Services we supply: ①OEM and ODM service； ②we supply customer brand printing onto the product and package for quantity orders; ③also supply software or OS design service, to load buyer's OS or design special softwares; ④supply computer design and I/O change as per buyer's requirement.

Drop shipping service: Drop shipping is a business model in which the retailer benefits from selling products to customers then ordering products from drop shipping providers. The only thing you need to do is pass the orders to Mini tree.Customers will receive the ordered products directly from Mini tree. This process minimizes the risk to you.

Our Services & Strength

1.Product quality : Quality is the best important for co-opertion .Our technical install RAM,SSD,WIFI and operation system to test each PC although barebone system your bought .Then every PCs must get through high quality test for a least 2 hours .

2.Brand configuration : Every pieces of accessories (memory, storage ,wireless card etc) , we used famous brands or chinese brand with top quality .

3.Service : Pricing , Selling , After-sale etc.

4.OEM : We accept OEM Service (such as logo printing , box , packing )

5.Leading time : We working with DHL Express to ensure the package will be transportated within 10 days .

6.Brand profection :We are a brand company and we will not Cheating customers 。
