China Factory Supply 3/4 Axles 20ft 40ft 53ft Curtain Side Semi Trailers
Van Box Semi Trailer Curtainsider Semi Trailer For Sale
Products Description
The curtainsider trailer is a form of the van semi-trailer. The curtain van semi-trailer is mainly used to transport all kinds of pallet goods such coils, drinks, pallets, light cargo, machines, etc. When loading and unloading goods, the curtains on both sides can be quickly opened, which can be used by forklifts. Loading and unloading goods on both sides at the same time, generally within 5minutes can load or unload the whole trailer, is currently one of the fastest loading and unloading cargo transportation tools, at the same time. the trailer also has the rain and dust proof of the van features.The design of the sliding roof on the side-curtain trailer can facilitate the loading and unloading of goods and could be remotely controlled.
Side Curtain trailers can load goods efficiently, not only because multiple forklifts can operate at the same time after the side curtains of the trailer are unfolded, but more importantly, the use of stan-dardized pallets to optimize the loading steps, and through the mutual combination of standardized pallets. the utilization rate of the container volume is maximized. In addition,reasonable cargo layout also helps to average vehicle axle loads, which can effectively improve vehicle driving safety while reducing vehicle wear and tear.
Product Name | 2 Axles | 3 Axles | 4 Axles |
Loading Capacity | 20-50 Tons | 30-60 Tons | 60-100 Tons |
L*W*H | 13000*2550*2400mm | 13000*2550*2400mm | 13000*2550*2400mm |
Door Position | Multi-Choice | Multi-Choice | Multi-Choice |
Main Beam Material | Q345/T700 | Q345/T700 | Q345/T700 |
Height | 500mm | 500mm | 500mm |
Upper Plate | 12mm | 14mm | 16mm |
Middle Plate | 6mm | 8mm | 10mm |
Lower Plate | 14mm | 16mm | 18mm |
Box Plate Thickness | 0.9mm | 0.9mm | 0.9mm |
Axles | 2*13T/16T FUWA/BPW | 3*13T/16T FUWA/BPW | 4*13T/16T FUWA/BPW |
Tire | 11.00R20/12R22.5*8 pieces,Linglong/Triangle/Double-Coin/Bridgestone | 11.00R20/12R22.5*12 pieces,Linglong/Triangle/Double-Coin/Bridgestone | 11.00R20/12R22.5*16 pieces,Linglong/ Triangle/Double-Coin/Bridgestone |
Rim | 9.0/8.0*8 pieces, steel/aluminum | 9.0/8.0*12 pieces, steel/aluminum | 9.0/8.0*16 pieces, steel/aluminum |
Suspension | Mechanical/ Air | Mechanical/ Air | Mechanical/ Air |
Leaf Spring | 90mm*13/16mm*10 pieces | 90mm*13/16mm*10 pieces | 90mm*13/16mm*10 pieces |
Landing Gear | Jost 28T two-speed | Jost 28T two-speed | Jost 28T two-speed |
King Pin | Jost 2''(50#)/3.5''(90#) changeable | Jost 2''(50#)/3.5''(90#) changeable | Jost 2''(50#)/3.5''(90#) changeable |
Tool Box | steel/aluminum | steel/aluminum | steel/aluminum |
Product Advantages
Details Images
Customer Feedback
Packaging ＆ Shipping
Company Profile
Shandong CJS Automobile Co., Ltd. is located in Qingdao, enjoying convenient transportation and beautiful environment. Our factory covers an area of 130000 square meters and has 290 employees. We are specialized in all kinds of semi trailers, full trailers, trucks, used trucks and trailers and related spare parts. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. In addition, we have obtained ISO9001 and WMI certificates. Selling well in all cities and provinces around China, our products are also exported to clients in such countries and regions as Africa, South America, Middle East, East Europe, etc.
We also welcome OEM and ODM orders. Whether selecting a current product from our catalog or seeking engineering assistance for your application, welcome to talk to our customer service center about your sourcing requirements.
Certifications
FAQ
Q1. What is the advantage about your company?
A1. CJS trailer is leading direct manufacturer, and has experienced staff in design and customer service.Our company has professional team and professional production line.Our products
are sold to Africa, Southeast Asia, the Middle East, East Asia, South Asia, Oceania, North America, South America, Central America, Eastern Europe, Western Europe, and Southern Europe.
Q2: Why should I choose your products?
A2: Reliable quality, fast delivery time within 15-45 days, warranty 3 years, thoughtful value-added services.
Q3: What is your product range?
A3: We mainly produce cargo trailer, tank trailer, lowboy trailer, trailer chassis, truck body, supply new and used truck, trailer and related spare parts. OEM/ODM/CKD/SKD available.
Q4: Can I custom my trailer freely?
A4: Yes, above 90% orders are customized.
ODM orders: just tell us the cargo size and weight, we will design it for you.
OEM orders: we produce according to your CAD or 3D drawing.
Q5.What services can you provide?
A5.Accept delivery terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES;
Accepting payment currencies: US dollars, euros, Canadian dollars, Australian dollars, Hong Kong dollars, British pounds, Chinese yuan, Swiss francs;
Payment terms accepted: T/T, L/C, D/P D/A, MoneyGram, credit card, PayPal, Western Union remittance, cash, custody;
Languages: English, Chinese, Spanish, Portuguese, German, Arabic, French, Russian
are sold to Africa, Southeast Asia, the Middle East, East Asia, South Asia, Oceania, North America, South America, Central America, Eastern Europe, Western Europe, and Southern Europe.
Q2: Why should I choose your products?
A2: Reliable quality, fast delivery time within 15-45 days, warranty 3 years, thoughtful value-added services.
Q3: What is your product range?
A3: We mainly produce cargo trailer, tank trailer, lowboy trailer, trailer chassis, truck body, supply new and used truck, trailer and related spare parts. OEM/ODM/CKD/SKD available.
Q4: Can I custom my trailer freely?
A4: Yes, above 90% orders are customized.
ODM orders: just tell us the cargo size and weight, we will design it for you.
OEM orders: we produce according to your CAD or 3D drawing.
Q5.What services can you provide?
A5.Accept delivery terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DEQ, DDP, DDU, Express Delivery, DAF, DES;
Accepting payment currencies: US dollars, euros, Canadian dollars, Australian dollars, Hong Kong dollars, British pounds, Chinese yuan, Swiss francs;
Payment terms accepted: T/T, L/C, D/P D/A, MoneyGram, credit card, PayPal, Western Union remittance, cash, custody;
Languages: English, Chinese, Spanish, Portuguese, German, Arabic, French, Russian
