S5735 S48S4XE V2 (48*GE SFP Ports 4*10GE SFP Without Power Module) HW Industrial Ethernet Switch
- Категория: >>>
- Поставщик: Chongqing Yujia Technology Co. Ltd.Chongqing Ltd.
Сохранить в закладки 1601296865120:
Описание и отзывы
Характеристики
Product Description
Item | Details |
Description | S5735-S48S4XE-V2 (48*GE SFP ports, 4*10GE SFP+ ports, without power module) |
Part Number | 98012232 |
Model | S5735-S48S4XE-V2 |
First supported version | V600R023C00 |
Remarks | When 1000BASE-X Ethernet optical ports use 25 or more GE optical modules with a distance of 40 km or longer, a power module with a minimum power of 180 W is required. |
The 1000BASE-X Ethernet optical ports can use a maximum of 24 copper modules at the same time. |
Details Images
Specification
Item | Specification |
Dimensions without packaging (H x W x D) [mm(in.)] | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.) |
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 446.0 mm (1.72 in. x 17.40 in. x 17.56 in.) | |
Dimensions with packaging (H x W x D) [mm(in.)] | 185 mm x 650 mm x 550 mm (7.28 in. x 25.59 in. x 21.65 in.) |
Chassis height [U] | 1 U |
Weight without packaging [kg(lb)] | 5.2 kg (11.46 lb) |
Weight with packaging [kg(lb)] | 7.1 kg (15.65 lb) |
Typical power consumption [W] | 72.3 W |
Typical heat dissipation [BTU/hour] | 246.69 BTU/hour |
Maximum power consumption [W] | 96.40 W (with two 80 W AC power modules) |
104.70 W (with two 180 W AC power modules) | |
130.05 W (with two 1200 W DC power modules) | |
Maximum heat dissipation [BTU/hour] | 328.93 (with two 80 W AC power modules) |
357.25 (with two 180 W AC power modules) | |
443.74 (with two 1200 W DC power modules) | |
Static power consumption [W] | 31.5 W |
MTBF [years] | 78.95 years |
MTTR [hours] | 2 hours |
Availability | > 0.99999 |
Noise at normal temperature (acoustic power) [dB(A)] | 43.8 dB(A) |
Noise at normal temperature (acoustic pressure) [dB(A)] | 31.80 dB(A) |
Number of card slots | 0 |
Number of power slots | 2 |
Number of fans modules | 2 |
Redundant power supply | 1+1 |
Power modules without fans and power modules with fans cannot be installed in the same chassis. | |
Long-term operating temperature [°C(°F)] | -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) |
Restriction on the operating temperature variation rate [°C(°F)] | When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
Devices cannot start when the temperature is lower than 0°C (32°F). | |
Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
Long-term operating relative humidity [RH] | 5% RH to 95% RH (non-condensing) |
Long-term operating altitude [m(ft.)] | 0–5000 m (0–16404 ft.) |
Storage altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
Power supply mode | Pluggable power supply |
Rated input voltage [V] | AC input: 100 V AC to 240 V AC; 50/60 Hz |
High-voltage DC input: 240 V DC | |
DC input: –48 V DC to –60 V DC | |
Input voltage range [V] | AC input: 90 V AC to 290 V AC; 45–65 Hz |
High-voltage DC input: 190 V DC to 290 V DC | |
DC input: -38.4 V DC to -72 V DC | |
Maximum input current [A] | The current specifications are related to the pluggable power module. For details, see Pluggable Power Modules. |
Memory | 2 GB |
Flash memory | Physical space: 1 GB |
Console port | RJ45 |
Eth Management port | Supported |
USB | Supported |
RTC | Not supported |
RPS input | Not supported |
Power supply surge protection [kV] | Configured with AC power modules: ±6 kV in differential mode and ±6 kV in common mode |
Configured with DC power modules: ±2 kV in differential mode and ±4 kV in common mode | |
Ingress protection level (dustproof/waterproof) | IP20 |
Types of fans | Built-in |
Heat dissipation mode | Air cooling for heat dissipation, intelligent fan speed adjustment |
Airflow direction | Air intake from left, front, and right and air exhaust from rear |
PoE | Not supported |
Certification | EMC certification |
Safety certification | |
Manufacturing certification |
