02353DJE S5731S H24T4S A 24*10/100/1000BASE T порты 4 * 1000BASE X сетевой коммутатор

02353DJE S5731S H24T4S A 2410/100/1000BASE T порты 4 1000BASE X сетевой коммутатор

Категория: >>>
Поставщик: Chongqing Yujia Technology Co. Ltd.Chongqing Ltd.

Цена:*

Количество:

В избранное

Описание и отзывы

Характеристики

Products Description

Part Number	02353DJE-001
Model	S5731S-H24T4S-A
Description	S5731S-H24T4S-A(2410/100/1000BASE-T ports,4GE SFP ports,1*150W AC power)

Details Images

Specification

Chassis material	Metal
Height [mm]	43.6 mm
Depth [mm]	420.0 mm
Wide [mm]	442.0 mm
Chassis height [U]	1
Weight with packaging [kg(lb)]	9.35 (20.61)
Weight without packaging [kg(lb)]	6.04 (13.32)
Maximum power consumption [W]	91
Typical power consumption [W]	70
Heat dissipation mode	Heat dissipation with fan, intelligent fan speed adjustment
Maximum heat dissipation [BTU/hour]	310.5
Typical heat dissipation [BTU/hour]	238.85
Power supply mode	Pluggable power supply
Input voltage range [V]	- AC input: 90–290 V AC; 45–65 Hz - High-voltage DC input: 190 V DC to 290 V DC - DC input: -38.4 V DC to -72 V DC
Rated input voltage [V]	- AC input: 100 V AC to 240 V AC; 50/60 Hz - High-voltage DC input: 240 V DC - DC input: –48 V DC to –60 V DC
Maximum input current [A]	The current specifications depend on the pluggable power modules in use. For details, see the related power module specifications.
Number of power slots	2
Number of card slots	0
Memory	4 GB
Flash memory	1 GB in total. To view the available flash memory size, run the display version command.
Redundant power supply	1+1 Pluggable AC and DC power modules can be used together in the same switch, but power modules that use natural heat dissipation and power modules that use air cooling cannot be used together.
Types of fans	Pluggable
Noise at normal temperature (acoustic power) [dB(A)]	57.5
Noise at normal temperature (acoustic pressure) [dB(A)]	47.5
Airflow direction	Air intake from front, air exhaustion from rear (front-to-rear)
Storage temperature [°C(°F)]	-40°C to +70°C (-40°F to +158°F)
Long-term operating temperature [°C(°F)]	-5°C to +45°C (23°F to 113°F) at an altitude of 0-1800 m (0-5906 ft.)
Restriction on the operating temperature variation rate [°C(°F)]	When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F).
Long-term operating relative humidity [RH]	5% to 95%, noncondensing
Storage altitude [m(ft.)]	0-5000 m (0-16404 ft.)
Long-term operating altitude [m(ft.)]	0-5000 m (0-16404 ft.)
MTBF [year]	57.73
MTTR [hour]	2
Availability	> 0.99999
Maximum number of physical ports on the entire device	28
Maximum number of 100GE ports	0
Maximum number of 40GE ports	0
Maximum number of 25GE ports	0
Maximum number of 10GE ports	0
Maximum number of GE ports	28
Maximum number of FE ports	24
1000M optical interface	4
1000M electrical interface	24
USB	Supported
Console port	RJ45
Eth Management port	RJ45
Service port surge protection [kV]	Common mode: ±6 kV
Power supply surge protection	- AC power module configured: ±6 kV in differential mode, ±6 kV in common mode - DC power module configured: ±2 kV in differential mode, ±4 kV in common mode
RPS input	Not supported
PoE	Not supported
