Electric heating pasteurizer & food sterilizing tank
Product Description
Application of plate heat exchanger pasteurizer
Brief introduction of plate heat exchanger pasteurizer
Sterilization principle is limited in a certain temperature range, the lower the temperature, the
slower the bacteria; higher the temperature, the faster propagation.
If the temperature is high enough, the bacteria will die. Different bacteria have different optimum
growth temperature, heat resistance, and cold capacity.
Pasteurization is actually not very resistant pathogens exploit the characteristics of treatment with
the appropriate temperature and time, kill them all. However, after pasteurization, there would still
retains a small portion of harmless or beneficial bacreria, compared with a heat-resistant bacteria
or bacterial spores.
Features of plate heat exchanger pasteurizer
| 1. | SUS304 stainless steel (thickness 2mm), sterilization temperature, speed can be set according to process requirements. |
| 2. | Bactericidal effect, low noise, speed adjustable durable, safe and reliable, automatic temperature control, easy maintenance. |
| 3. | The body is made of milk cans and tanks of two part. |
| 4. | Hot water tank and water tank into the cold water tank. |
| 5. | Tank is divided into three layers, the outermost layer is the insulation layer, an intermediate layer of hot water sterilization, the inner layer is milk. |
| 6. | The top of the milk cans with a stirrer, stir milk to make milk is heated evenly through the mixing device. |
| 7. | Barrel diameter of 500-600mm, the yield of 100kg/second (150kg/times). |
| 8. | To pasteurized milk at a temperature of about 4 °C preservation, and can only save 3-7 days |
Models of plate heat exchanger pasteurizer
| 1. | Most cost-effective model: tank type |
| 2. | Most popular type: inclusive financial type |
| 3. | Best cost performance type: water cooling system type |
| 4. | Most practical model: ice cooling system type |
| 5. | Most advanced model: air compressor cooling system type |
| (Our milk pasteurizer has the agitator, so the milk can be heated evenly. Also there is a thermameter which can show you the temperature during pasteurizing. At last, make the milk taste good. In addition, we have ISO certification which can proof the quality of our milk pasteurization machine.) | |
Parameters of plate heat exchanger pasteurizer
Item | RL-150 Air Compressor Type | RL-150 Ice Cooling System Type | RL-150 Water Cooling Type | RL-150 Inclusive financial type |
Diameter of barrel | 625mm | 625mm | 625mm | 630mm |
Height of barrel | 1140mm | 1140mm | 1140mm | 905mm |
Inside height of barrel | 620mm/605mm | 620mm/605mm | 620mm/605mm | 420mm/405mm |
Capacity | 50-150kg/batch | 50-150kg/ batch | 30-150kg/ batch | 30-100kg/batch |
Material | Sus304 | Sus304 | Sus304 | Sus304 |
Thickness | 2mm | 2mm | 2mm | 2mm |
Height of machine | 1900mm | 1900mm | 1500mm | 1000mm |
Sterilizing time | 10-30min (adjustable) | 10-30min (adjustable) | 10-30min (adjustable) | 10-30min (adjustable) |
Sterializing temperature | 60-99 degrees (adjustable) | 60-99 degrees (adjustable) | 60-99 degrees (adjustable) | 60-99 degrees (adjustable) |
HP | 3HP | 3HP\\2HP | 2HP | 2HP |
Heating cycle | 25-35min | 25-35min | 25-35min | 25-35min |
Voltage/ power | 380v/13kw | 380v9kw/220v 6kw | 380v9kw/220v 6kw | 380v9kw /220v 6kw |
Dimension | 1900*800*1980 | 1900*800*1980 | 1400*780*1530 | 910*740*1300 |
Net weight | 400kg | 320kg | 170kg | 168kg |
More details parameters of related models, pls kindly contact Iris when you feel free!
Pictures of plate heat exchanger pasteurizer
Packaging & Shipping
Export wooden package.
By sea, by air, or via DHL, UPS, TNT, FEDEX, EMS etc.
(We'll choose the most suitable way and lowest delivery cost for you.)
