KingSpec 64GB 1.8 inch CF IDE 50pin SSD

Factor: 1.8 inch
Interface: IDE

Capacity: 8 to 128GB
Flash type: MLC NAND flash
Maximum sustained reading speed: 85MB/s
Maximum sustained writing speed: 53MB/s
ECC supports BCH ECC 8 or 15 bits in 512 bytes
Operating temperature: 0 to 70
Warranty: 3 years
Packing: standard gift box

Features:
Less Power Usage
Faster Data Access
Higher Reliability
Noise Free

Specification:
Item Model KSD-CF18.6-064MS
General Form factor 1.8"
interface 50pin IDE(CF) Interface
Performance Capacity(GB) 64GB
Sustained Read 65MB/S
Sustained Write 40MB/S
Random IOPS 5.585
Average Access time 0.2ms
Storage Media NAND Flash MLC-NAND Flash
Power Consumption input Voltage 3.3V ± 5%
Idle 0.5W
Active 1.0W
Read endurance unlimited
Wear-Leveling Algorithm Dynamic and static wear-leveling
Data Retention 10years at 25ºC
MTBF 1,000,000hours
ECC Supports BCH ECC 8bits or 15bits in 512 bytes
Bad Block Management Auto Bad Block Management in system
Environment Operating Temperature 0~70ºC
Non-operating Temperature -40~85ºC
Shock 2,000G(@0.3ms half sine wave)
Vibration 20G(40-2000HZ)
Humidity 5-95%
Warranty 3years
Available unit Available,NO EOL
Testing Software HDBench3.4.0.3, IOMeter 2006.07.27
Physical Dimensions
& Weight Height(mm) 5.0± 0.25
Width(mm) 54± 0.25
Length(mm) 74.5± 0.25

Compatible Models:
Sony TR2 / TR3 / TR5 / DV-SR80 / HD3 / HD5 / Portege 2000 / SS2000M / P2010 / R100 / R200 ,
Libtrtto U100 / Fujisu Q20100 / P7230 / P7120 / P1610 / T70 / FMV-BIBLO , HP NC2400. SAMSUNG Q3

Package include:
1x KingSpec Hi-Speed 64GB 1.8 inch CF IDE 50pin SSD For Sumsang Q30 Toshiba Sony Fujitsu

What is Solid state drive?

Solid State Drives, which use flash memory instead of a hard-drive platter to store date.

Old computers had a habit of spitting files and spreading the parts all over your hard drives, but modern ones don’t do this as much. Not even close, a bimonthly pass with a capable Defragger can help you maintain peak performance on a heavily used hard drive.

Data transfer to and from solid-state drives is much faster than electromechanical disk drives. Seek time and latency are also substantially reduced. Users typically enjoy much faster boot times as well. In general, SSDs are also more durable and much quieter, with no moving parts to break or spin up or down. SSDs do, however, have slower write times and a set life expectancy, as there is a finite number of erase/write cycles before performance becomes erratic.

Our products’Competitive Advantage:

1)Original brand NAND Flash
2)Fast read/write speed, faster application load times
3)High reliability, data stability
4)Low energy consumption
5)Anti-shock, anti-dust, noiseless, superior security
6)Shockproof, rugged design safe and high stability and reliability

KingSpec Electronic Technology company’s brief introduction:

We KingSpec are a solid state disk manufacturer, specialized in designing, developing, manufacturing and selling SSD products as well as other storage devices like USB flash drives, memory card, and dom. Besides designing and producing our products, we also do the OEM and ODM. Our factory had passed ISO9001:2008 certification and had membership with SSDA, the SSDs are CE, FCC certificated. After several years of effort, our independent R&D SSD products have entered the global market successfully and won excellent public praise from our client comes from Europe, America, Southeast Asia and many other countries.
