BLM-IS38-01 Compact LED Optical Tester





Overview


The BLM-IS38-01 Compact LED Optical Tester, with the wavelength range of 350nm-1050nm and optical resolution of ~1nm, can measure LED's optical parameters, such as peak wavelength, center wavelength, half-peak width, power, color temperature, and chromaticity coordinates. The BLM-IS38-01 is compact and easy to be integrated by the fixing holes on the side and bottom. It is customizable, supports RS232 / RS422 communication, enhances anti-jamming performance, provides SDK, and is more suitable for industrial and scientific research.





Applications


Measure the peak wavelength, center wavelength, half-peak width, power, color temperature and chromaticity coordinates of low-power LEDs





Features


Compact and easy to be integrated


Wide wavelength range, not only covering the visible light range


With the auto-peak function, can quickly find out the peak's center wavelength and FWHM


Measure the color temperature, chromaticity coordinates and other parameters in real time


USB2.0 for data and power


Support RS232 / RS422


Absolute intensity calibration, NIST traceable


Customizable and SDK is available





Dimensions









Specifications























































Parameters



Measurable LED



LED diameter ≤ 9mm



Optical Parameter



Wavelength range: 350nm – 1050nm


Optical resolution: ~ 1nm



Wavelength / FWHM



With the auto-peak function, can quickly find out the peak's center wavelength and FWHM


Wavelength accuracy: 0.7nm


Minimum measurable FWHM: 1nm



Optical Power



Relative power


Absolute power (requires absolute power calibration service)



Colorimetry



Complies with CIE standards, can measure color temperature, chromaticity coordinates, color purity and color rendering index


Chromaticity coordinate repeatability: ± 0.001



Dimension



180mm x 80mm x 71mm



External trigger



Software trigger, hardware trigger, synchronous trigger



Power supply



USB 2.0; 5VDC, 500mA



Operating temperature



5 - 35 (25 ℃ recommend)



Communication



USB2.0,12Mbps


RS232/RS422,115200bps



Operating system



Win XP,Win7,Win8,Win10






Measurements




Optical power measurement




Wavelength and FWHM measurement




Color measurement





Packing List


1 x device, 1 x USB cable, 1 x CD (including software, user manual, calibration file), 1 x calibration report





Further Information


The LED fixture can be customized


Tungsten light source (BIM-6210) for relative intensity calibration is optional.
