CompAir

D75 D90 D110 D132 D160 D165 D200 D250 D315

CompAir D-Series air compressor with 0 oil injected

D-Series
Air purity that meets the most stringent hygienic standards

Outstanding reliability for demanding applications

CompAir has launched a completely new range of high efficiency, oil-free two-stage screw compressors to further enhance its successful and award winning D-Series. With the addition of ten new models, the D-Series now covers a wide flow range from 8.9 to 51.8 m³/min. The new models (from 160 to 315kW), which also utilise a CompAir designed and manufactured two-stage airend, offer oil-free and silicone-free air, in accordance with ISO 8573-1 Class 0.

The sophisticated Delcos XL controller protects your investment by continuously monitoring operational parameters. CompAir's own designed and manufactured airend works at constant low temperature levels and lowers the compressor’s lifecycle costs.

With easy servicing and full Assure warranty cover, operators eliminate all possible risks to their business.

BENEFITS:

·        Premium efficiency two stage airend design

·        High quality IE3 or IE4 electric motor

·        Efficient motor cooling

·        High ambient temperatures of up to 45°C

·        Delcos XL touch screen controller with enhanced monitoring

·        Unique closed cooling water circuit for airend cooling

·        Water cooled models available

·        Two high efficiency radial cooling fans in accordance with ErP Efficiency Legislation 2015

DESIGN:

The high output, two stage airend design provides 100% oil-free and near isothermal compression with high reliability thanks to constant low temperatures, allowing use in demanding applications in up to 45°C ambient temperatures.

Guaranteed efficiency is provided by the excellent IE3 electric motor, along with legal conformity, high reliability and operational safety - great benefits in addition to automated motor lubrication.

The compressors utilise two efficient radial fans in accordance with ErP Efficiency Legislation 2015, offering low noise levels, low pressure loss and excellent cooling performance. The closed water circuit for airend cooling achieves a constant low temperature level, also meaning that less gearboxes are required.

CONTROLLER:

Delcos XL touch-screen controller

The multilingual Delcos XL control system ensures reliable operation and protects your investment by continuously monitoring the operational parameters, which is essential for reducing cost of ownership.

·        Precise monitoring for exceptional operational reliability

o   Ambient pressure and temperature

o   Inlet and outlet pressure and temperature at both stages

o   Network pressure and temperature

o   Oil / water pressure and temperature

o   Oil / water level

o   … and many more

·        High resolution, easy-to-use touch-screen panel

·        User-friendly clear menu structure

·        Integrated SD card for in-depth analysis of monitored machine parameters

·        Optional base load sequencing

·        Trend diagrams for

o   Network pressure

o   Motor speed (regulated speed models)

o   On load hours / total running hours and average volume flow

o   Weekly average volume flow

MODELS:

CompAir D - Technical Data

D75 - D315 Fixed Speed

D110RS - D315RS Regulated Speed

CompAir

DH-Series
Water injected rotary screw compressor

 D15H D22H D37H

D15HRS D22HRS D37HRS D50HRS D75HRS D110HRS

Oil Free

100% air purity, that meets the stringent quality standards.

Air purity is critical for many applications where even the tiniest drop of oil can cause product spoilage or damage production equipment. CompAir offers a wide range of oil-free compressor technologies, each one built to give you the peace of mind that comes with high-quality air supply.

·

DH-Series
Water injected rotary screw compressor

·

S-Series
Contaminant free. Risk free. 100% Oil-free

·

D-Series
Air purity that meets the most stringent hygienic standards

·

Quantima®
The Next Generation of Efficiency

·

R-Series
High-output two-stage piston compressors

·

Ultima™
Revolutionary Energy Efficiency

DH-Series
Water injected rotary screw compressor

CompAir DH - 100% air purity that meets stringent quality standards

The DH series contains absolutely no oil anywhere in the compressor and has been certified ISO 8573-1 Class Zero (2010) and silicone free.

The unique design achieves lower speeds combined with lower operating temperatures - both resulting in high efficiency and reduced component wear. Using a single-stage, direct-driven motor without gears or belts, maximises efficiency. Limiting the compressed air to the application demand with regulated speed ensures that no energy is wasted.

BENEFITS:

·        Single-stage, direct-driven compression element maximises efficiency and minimises maintenance

·        High quality water injection lubricates, cools and seals the compression process, maximising efficiency

·        No gearbox means no need for associated oil lubrication

·        Low bearing loads and low speeds mean sealed-for-life bearings can be used, requiring no oil lubrication

·        Regulated speed technology available to reduce energy costs

·        Comprehensive control ensures safe and reliable operation and includes remote communication capability

·        Fully packaged and silenced enclosure reduces noise and simplifies installation

DESIGN:

DH compressors have significantly fewer moving parts than comparable machines, meaning there is less to go wrong, while lower speeds and balanced bearing loads extend the compression element service life for low-cost operation.

With exceptionally low running temperatures of less than 60°C near isothermal compression is achieved. This also eliminates the need of an internal aftercooler and associates power consumption reducing pressure drop to the minimum.

The compression loads are balanced resulting in low bearing loads and highest reliability:

The tried and tested reverse osmosis filtration provides high quality purified water to lubricate, seal and cool the compression process. Using a permeate pump the water required is reduced to a minimum.

CONTROLLER:

Delcos XL touch-screen controller

The multilingual Delcos XL control system ensures reliable operation and protects your investment by continuously monitoring the operational parameters, which is essential for reducing cost of ownership.

·        Precise monitoring for exceptional operational reliability

o   Ambient pressure and temperature

o   Inlet and outlet pressure and temperature at both stages

o   Network pressure and temperature

o   Oil / water pressure and temperature

o   Oil / water level

o   … and many more

·        High resolution, easy-to-use touch-screen panel

·        User-friendly clear menu structure

·        Integrated SD card for in-depth analysis of monitored machine parameters

·        Trend diagrams for

o   Network pressure

o   Motor speed (regulated speed models)

o   On load hours / total running hours and average volume flow

o   Weekly average volume flow

·        Optional base load sequencing

MODEL:

CompAir DH — Technical Data

Fixed Speed — Air and Water Cooled

Regulated Speed — Air and Water Cooled
