0.3 1mm, 2mm 3mm high efficiency steel coils cross slitting line / cutting to length slitter machine
- Category: >>>
- Supplier: Botou Golden Integrity Roll Forming Machine Co. Ltd.
Share on (10000007487519):
Product Overview
Description
Product Description
Botou Golden Integrity Roll Forming Machine Co.,Ltd. we has been established in 1995 as a professtional manfuactures of Roll Forming Machine. We use Auto CAD design software,. With more than 20 years of experiences and strict quality control, our products meet international standards. We are leading manfuacture and reported of roll forming machine in China. We manufacture various kinds of roll forming machines for producing the following products.Such as roof tile, wall panel, roll shutter door, downspout, decorated gusset, steel pipe, guardrail sheet, etc.
Our products with rational stucture, good looking and duration, have been exported to Uganda, Bolivia, Uruguay, Nigeria, Ghana, Vietnam, Myanmar, Russia, Kazakhstan, Turkmenistan. India, Philippinese etc.
1.Roll forming machine: color steel GI.PPGI. Aluminum coil cut to length machine
Different thickness for 0.8mm 1mm. 2mm. 3mm etc
2. Size:3500*14000*14000
3. Certification: ISO9001, SGS, CE,
Product Name | color steel roof sheet crimping machine |
Suitable material | Cold rolled coil,hot rolled coil, galvanized coil |
Q235Mpa.Q350Mpa,Q550Mpa | |
0-3.0mm (Customized) 0.2-1.0mm or more | |
Coil | Feeding Width: 1220mm (customized) |
Forming speed | 0-20m/min |
Roller stations | 5 stations |
Material of roller | 45# steel finish maching , plated hard |
Hardness of roller | HRC: 58-62 |
Material of main shaft | 45# steel finish maching , then slack |
Driven motor power | 3 Kw |
Hydraulic station pressure | 12.0 Mpa |
Electrical control system | Panasonic PLC |
Hardness of cutter | HRC: 58-62 |
Driving mode | Single chain 1inch |
Power supply | 380V, 60Hz, 3 Phase or as per request |
Cutting accuracy | ±1.5mm |
Dimension(L*W*H) | 300mm* 1400mm*1400mm |
Products Show
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
High quality
Passed the ISO9001:2008 quality system authentication and ROHS authentication.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
Warranty:
Two years, and we will provide technical support for whole life of the equipment. If some parts of machine broken within
2 year, we will give customer the spare parts for free. (include chain, bearing, roller,oil pipe, counting wheel) If more than 2
year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is
perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.
2 year, we will give customer the spare parts for free. (include chain, bearing, roller,oil pipe, counting wheel) If more than 2
year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is
perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.
Our Company
Warehouse
Team
Packing & Delivery
Packing Details : Shippment standard packing, waterproof wrapped, Fixed in 20', 40'GP container.
Delivery Details : 30-35 working days after receiving the deposit.
1. plastic wrapped packaging
2. Loading in workshop
3. Fixed to the container
Our Certifications
We are factory specializin in the manufacture for all kinds of roof r ile roll forming machines for more than 20 years. With professional engineers, accept higher standard.
FAQ
Q: Are you trading company or manufacturer ?
A: We are factory.
Q: How long is your delivery time?
A: Generally it is 1-5days if goods are in stock. 25-30 working days if goods not in stock.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.
Q: What is your terms of payment ?
A: 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us as below:
Any questions, please tell me freely, I will try best to help you.
Full auto C AND Z purlin interchangeable roll forming machine
Automatic high quality rain gutter roll forming machine
Hot sale double layer steel roofing panle roll forming machine
2inch 3 inch Steel Floor decking roll forming machine
New model Steel glazed tile roofing panel cold roll forming machine
2 wave & 3 waves steel crash barrier roll forming machine
If no idea for the design, I will recommend for you. No need to hesitate to contact us.
