1KVA 1KW rack and tower type online uninterrupted power supply ups long backup power
- Category: Batteries >>>
- Supplier: POWERCOM CO. LTD.
Share on (10000008322202):
Product Overview
Description
Products Overviews
POWERCOM MRT online series output high quality power factor 1.0 current, providing reliable protection and great UPS performance for users. This series is equipped with an auto-self rotated LCD display for clearly informing indications.
In addition, multi-sections fan regulation design for reducing the operating noise. And the UPS management systems are able to schedule UPS program, monitor UPS on-time status by portable device.
MRT UPS is the best choice of safe-guard for server, data center, storage equipment and network equipment.
Features:
- Power Factor 1.0
- Pure sine wave output with double conversion technology
- Extremely low THD suitable for delicate instruments
- Diagram LCD with auto-rotation for better user experience
- Hot swappable battery replacement for easy maintenance
- Overload, surge, short circuit protection
Model | MRT-1000 | MRT-1500 | MRT-2000 | MRT-3000 | MRT-6000 | MRT-10K | ||||||
Configuration | ||||||||||||
Capacity (VA) | 1000 VA | 1500 VA | 2000 VA | 3000 VA | 6000 VA | 10 KVA | ||||||
Capacity (Watts) | 1000 W | 1500 W | 2000 W | 3000 W | 6000 W | 10 KW | ||||||
Form | Rack and Tower Type | |||||||||||
Phase | Single Phase | |||||||||||
Energy Saving | Yes - ECO Mode Efficiency >94% | |||||||||||
Input | ||||||||||||
Voltage | 100 / 110 / 120 / 127 or 208 / 220 / 230 / 240 VAC | 208 / 220 / 230 / 240 VAC | ||||||||||
Input Voltage Range | 60 - 144 VAC, < 25% Load 120 - 276 VAC, < 25% Load 70 - 144 VAC, < 50% Load 140 - 276 VAC, < 50% Load 80 - 144 VAC, < 75% Load 160 - 276 VAC, < 75% Load 90 - 144 VAC, < 100% Load 180 - 276 VAC, < 100% Load | 120 - 276 VAC, < 25% Load 140 - 276 VAC, < 50% Load 160 - 276 VAC, < 75% Load 180 - 276 VAC, < 100% Load | ||||||||||
Input Frequency Range | 50 / 60 Hz (Auto Sensing) | |||||||||||
Input Power Factor | >0.97 | |||||||||||
Cold Start | Yes | |||||||||||
Output | ||||||||||||
Rated Power Factor | 1.0 | |||||||||||
Waveform | Pure Sine Wave | |||||||||||
Voltage | 100* / 110* / 120 / 127 VAC ± 2% or 208* / 220 / 230 / 240 VAC ± 2% | 208* / 220 / 230 / 240 VAC ± 2% | ||||||||||
Frequency | 50 / 60 Hz ±0.25 Hz | |||||||||||
Transfer Time | 0 ms | |||||||||||
Harmonic Distortion | ≦ 2.5% THD at Linear Load | ≦ 3% THD at Linear Load | ||||||||||
Crest Factor | 3 : 1 | |||||||||||
EPO Function | Option | |||||||||||
Protection | ||||||||||||
Overload(Line Mode) | 105% - 120% for 30 seconds 121% - 150% for 10 seconds | |||||||||||
Overload(Battery Mode) | 101% - 109% for 10 seconds 110% - 120% for 3 seconds | |||||||||||
Surge Protection | IEC 61000-4-5 Level 3 | |||||||||||
Bypass | Internal Bypass (Automatic and Manual) | |||||||||||
Short Circuit Protection | UPS Output Cut Off Immediately | |||||||||||
Battery | ||||||||||||
Type | 12V 7Ah | 12V 9Ah | 12V 7Ah | 12V 9Ah | 12V 5Ah | 12V 9Ah | ||||||
Intermal Batt. | Yes | Yes | Yes | Yes | External Batt. | External Batt. | ||||||
Quantity | 3 | 3 | 6 | 6 | 20 | 20 | ||||||
Sealed, Maintenance Free | Yes | |||||||||||
Typical Recharge Time | 4 hr to 90% | |||||||||||
External Battery Module | Option | |||||||||||
External Battery Connector | Option | |||||||||||
Management & Communication | ||||||||||||
LCD Control Panel | Yes | |||||||||||
Communication Port | RS 232, USB B type | |||||||||||
SNMP Slot | Option | |||||||||||
Audible Alarms | Yes | |||||||||||
Physical(Power Module) | ||||||||||||
Dimensions (WxDxH) (mm) | 428 x 425 x 84 | 428 x 635 x 84 | ||||||||||
Weight (kgs) | 14.7 | 16.2 | 26.2 | 29 | 15.8 | 20 | ||||||
Shipping Dimensions (mm) | 546 x 552 x 206 | 550 x 750 x 220 | ||||||||||
Shipping Weight (kgs) | 17.5 | 19 | 30 | 33.4 | 19.6 | 24 | ||||||
Physical(Batt. Module) | ||||||||||||
Dimensions (WxDxH) (mm) | 428 x 425 x 84 | 428 x 635 x 84 | 428 x 635 x 84 (2U) | 428 x 657 x 130 (3U) | ||||||||
Weight (kgs) | 20.7 | 37.3 | 42 | 68 | ||||||||
Shipping Dimensions (mm) | 546 x 552 x 206 | 500 x 750 x 220 | 500 x 750 x 220 | 590 x 830 x 370 | ||||||||
Shipping Weight (kgs) | 23.4 | 40.8 | 45.6 | 83 | ||||||||
