Станок для резки металла с квадратной колонкой GB42130

Product Overview

Description

Model: GB42130-S



Cutting capacity	(Dia.)	1300(mm)
	(square)	1300*1300(mm)
Blade speed		17~58(m/min)
Blade Size		1.6x67x12100(mm)
Main Motor		15(kw)
Hydraulic Motor		3(kw)
Machine Size(LxWxH)		5670x4500x3730(mm0
Workpiece Clamping		Hydraulic





Square column metal band sawing machine

Main features:

Columns on both sides are gantry structure.

Flat block automatic feeding.

Hydraulic control sawing feed.

Double lift cylinder.

Dual front and rear blade hydraulic clamping jaws.

Hydraulic blade tension.

The main motor through inverter frequency, to can achieve continuously variable speed saw blade line.







About us

our  company   Zhejiang Aolinfa machine tool Co. Ltd. (former zhejiang jinyun huadong machine tool plant) was established in 1988. it is a band saw enterprise manufacturing horizontal, vertical, double column and planer-type metal band sawing machine . covers an area over 20,000 square meters and has total assets over RMB90 million .it has be engaged in band saw manufacturing for decades and accumulate rich band saw manufacturing experience and strong technology designing capacity .



9 years export experience  bring  the best service to you .we have more than 9 years export expereience. our products have been exported to Signapore,Russia,Qutar,AE, Ethiopia,Hungary,egypt,etc
