500L yogurt fermenter and milk cooling tank and pasteurizer

 500Lmilk pasteurizer full specification

Product advantage

1)        Made of stainless steel, suitable for food and beverage production

2)        Electric operated

3)        With temperature gauge <range 0~150degree>

4)        CIP friendly

5)        Digital temp control and display

Structure

• 3 layer of walls contracture, with top class thermal insulation performance
• Inner wall and middle wall make up the jacket which allowed thermal oil and heating elements working in it.
• Conical bottom, easy to discharge
• high effectively, low energy waste

Contraction material

²  Stainless steel 304

²  Motor power: 0.75KW

²  Agitator speed: 36rpm

Tank dimension

u  Inner diameter: 800mm

u  Outer diameter: 960mm

u  Inner height: 1000mm

u  Total height: 1650mm

500L milk fermentation tank

Product advantage

ü  Made of stainless steel, suitable for food and beverage production

ü  Designed with jacket, allowed for hot water or steam heating, as well as tap water cooling

ü  With temperature gauge <range 0~150degree>

ü  With glass level meter

ü  CIP friendly

Structure

• high effectively, low energy waste
• Double wall contracture
• The two walls make up the jacket which allowed hot water and cooling water pass through.
• Conical bottom, easy to discharge
• Sealed top, sanitary and prevent dirt in air fly in the tank effectively

Contraction material

²  Stainless steel 304

²  Motor power: 0.55KW

²  Agitator speed: 36rpm

Tank dimension

u  Inner diameter: 800mm

u  Outer diameter: 960mm

u  Inner height: 1000mm

u  Total height: 1650mm
