ESR 1300x4.5 TTMC Электрический скольжение машины с барабаном

Product Overview

Description



Electric Slip Roll Machine

MODEL:ESR-1300X4.5



Features



1. Asymmetrical roll bending machine with 3 high strength steel rolls



2. Fixed top roller, adjustable lower and rear rollers



3. The maximum processing capacity of the heavy electric rolling machine can reach 4.5 mm



4. The electric rolling machine not only reels but also can cone the materials



5. It can roll the round bar steels whose specifications are ¢6, ¢8, ¢10 and so on.



6. The electric rolling machine features a roller quenching that is more durable



7. The upper axis is fixed. The electric rolling machine runs through adjusting the lower and rea axes



8. The locking structure of upper roller can smooth the roller’s operation



9. The 24V pedal switch is safe and easy to operate



10. The safety mechanism of electric rolling machine is in line with the CE standard







Technical  Specifications



Item No.	Model	Max.Thickness(mm)	Max. width(mm)	Dia.of roll(mm)	Motor Power(kW)	Packing size(cm)	N.W./G.W.(kg)
391104	ESR-1300x2.5	2.5	1300	90	1.5	200x72x120	540/600
391105	ESR-1300x4.5	4.5	1300	120	2.2	200x76x127	750/830
391106	ESR-1550x3.5	3.5	1550	120	2.2	222x76x127	790/890
391107	ESR-2020x3.5	3.5	2020	127	40	270x87x130	1100/1300
391108	ESR-1300x6.5	6.5	1300	150	3	282x87x134	1100/1190
391109	ESR-2070x2.5	2.5	2070	120	2.2	282x87x130	1060/1200
391110	ESR-2070x3.5	3.5	2070	127	3	282x87x130	1110/1250
