Free shipping mini dumper sobre orugas sino truck dumper dimensions with different weight
- Category: Dump Trucks >>>
- Supplier: Shandong Nuoman Engineering Machinery Co. Ltd.
Share on (1600068601583):
Product Overview
Description
Product Description
Soft, wet or perilously uneven ground can present quite a challenge to a dump truck or pickup, especially when you need to move a heavy load from Point A to Point B. Getting stuck can put a big dent in productivity. That’s not a problem with a powerfully compact Tracked Carrier. The durable rubber tracks give you the high-flotation, low ground pressure capability to productively operate in muddy, sloppy, gnarly conditions, while minimizing disturbance to environmentally sensitive areas. These rugged carriers can get into, around or under a lot of spaces that nothing else mechanized can. Plus, each comes with a powerful, emissions- compliant, fuel-efficient diesel engine, so you won’t waste precious uptime – or money – with endless fill-ups.
Model | NM-SLD08 | Load Weight | 350kg |
Minimum height from the ground | 140mm | Gear | 3forward gears, 2reverse gears |
Track ground length | 800mm | Walking speed | forward :1.8-6.1km/h, reverse :1.8-3.6km/h |
Engine/ power | Gasoline/Diesel 10hp | Cargo box size | 1140*720*360mm |
Track center distance | 500mm | Dimensions | 1920*770*1070mm |
Track width | 180mm | Net Weight | 358kg |
Start method | Start method | Gradeability | 20 |
Support customized according to requirements
Lifts bucket
Shredder
Cranes
Custom seat
diesel/gasoline
Remote control
Other products
Crawler dumper
Wheel dumper
Crawler Dump Truck | ||||||||||
Model | NM-D2T | NM-D3T | NM-D4T | NM-D6T | NM-D8T | |||||
Net weight(kg) | 1200 | 1400 | 1400 | 1650 | 2800 | |||||
Vehicle size (m) | 3.35*1.5*1.7 | 3.35*1.56*1.74 | 3.65*1.62*1.74 | 3.95*1.74*1.8 | 3.9*2*1.98 | |||||
Size of bucket (m) | 2*1.5*0.6 | 2.2*1.5*0.6 | 2.3*1.6*0.6 | 2.5*1.8*0.6 | 2.5*2*0.8 | |||||
Track ground length (m) | 1.28 | 1.95 | 1.95 | 1.95 | 2.4 | |||||
Lowest point above the ground (cm) | 26 | 26 | 26 | 26 | 26 | |||||
Diesel engine power (kw / r / min) | 18.3/2200 | 22/2200 | 38/2400 | 50/2400 | 60/2200 | |||||
Load capacity (kg) | 2000 | 4000 | 4000 | 6000 | 8000 | |||||
Transmission Gear | 6 forward gears, 2 reverse gears | 3forward gears, 1reverse gears | ||||||||
Maximum flat road load (kg) | 2500 | 3000 | 2800 | 4000 | 4000 | |||||
Maximum slope load (kg) | 1800 | 2200 | 2800 | 4000 | 4000 | |||||
Max driving speed | 12km/h | 12km/h | 15km/h | 15km/h | 15km/h | |||||
Min driving speed | 2.5km/h | 2.5km/h | 2.5km/h | 2.5km/h | 3km/h | |||||
Climbing ability | Up to 40 degree , 20cm vertical obstacle | Up to 35 degree , 28cm vertical obstacle | ||||||||
Wading depth | 35cm | 45cm | 45cm | 45cm | 50cm | |||||
