Advanced Operation system High Speed Pill press Rotary Tablet Press Machine
- Category: Other Pharmaceutical Machinery >>>
- Supplier: Wenzhou Urban Machinery Co. Ltd
Share on (1600245607192):
Product Overview
Description
Products Description
Application
This machine is one kind of double side rotary tablet press machine, which can press granular materials into round shape tablet, irregular tablet or double-side engraved tablet.
This machine is mainly used in pharmaceutical, chemistry, foodstuff, electronic industries.
This machine is one kind of double side rotary tablet press machine, which can press granular materials into round shape tablet, irregular tablet or double-side engraved tablet.
This machine is mainly used in pharmaceutical, chemistry, foodstuff, electronic industries.
Feature:
1.High speed with large quantity punches, double press rollers, suitable for mass production.
2.Made of stainless steel, the housing is fully closed. The surface of the rotary turret is covered with a hardened layer so that the turret surface is wear resistant. The machine conforms to GMP requirements.
3.Perfect tableting system, twice compression forming, reasonable framework with proper space and big pressure roller, machine performance is reliable and no tablet weight difference.
4.Double impeller type force feeder, improve granules flow-ability and filling performance, ensure the filling precision.
5.Tooling track adopt double-side lifting structure, the punches are balanced stress and wear resistance.
6.High performance electrical control system, ensure each program processing precisely.
7.Automatic oil&grease central lubrication system, ensure the lubrication of pressure rollers, toolings and tracks, extending the working life of the machine.
8.Special oil proof, dust proof and noise proof design.
1.High speed with large quantity punches, double press rollers, suitable for mass production.
2.Made of stainless steel, the housing is fully closed. The surface of the rotary turret is covered with a hardened layer so that the turret surface is wear resistant. The machine conforms to GMP requirements.
3.Perfect tableting system, twice compression forming, reasonable framework with proper space and big pressure roller, machine performance is reliable and no tablet weight difference.
4.Double impeller type force feeder, improve granules flow-ability and filling performance, ensure the filling precision.
5.Tooling track adopt double-side lifting structure, the punches are balanced stress and wear resistance.
6.High performance electrical control system, ensure each program processing precisely.
7.Automatic oil&grease central lubrication system, ensure the lubrication of pressure rollers, toolings and tracks, extending the working life of the machine.
8.Special oil proof, dust proof and noise proof design.
Model | GZPK-51 | GZPK-63 | GZPK-75 | GZPK-81 | ||
Number of Stations | 51 | 63 | 75 | 81 | ||
Max Main Pressure (KN) | 100 | 100 | 100 | 100 | ||
Max Pre-pressure (KN) | 100 | 100 | 100 | 100 | ||
Max Tablet Diameter (mm) | round tablet | 25 | 18 | 13 | 13 | |
Max Tablet Diameter (mm) | irregular tablet | 25 | 19 | 16 | 15 | |
Max Filling Depth (mm) | 20 | 18 | 15 | 15 | ||
Max Tablet Thickness (mm) | 8 | 7 | 6 | 6 | ||
Max Production Capacity (pcs/h) | 428400 | 529200 | 630000 | 6800000 | ||
Motor Power (kw) | 15 | 15 | 15 | 15 | ||
Overall Size (mm) | 1780×1660×1920 | 1780×1660×1920 | 1780×1660×1920 | 1780×1660×1920 | ||
Machine Weight (kg) | 4800 | 4800 | 4800 | 4800 | ||
Characteristics:
1. Design of GMP.
2. High quality all stainless steel constructions.
3. Reliable safety sealing system and dust-proof system.
4. High visibility isolated door to prevent cross contamination.
5. Easily remove parts for quick machine’s maintenance.
1. Design of GMP.
2. High quality all stainless steel constructions.
3. Reliable safety sealing system and dust-proof system.
4. High visibility isolated door to prevent cross contamination.
5. Easily remove parts for quick machine’s maintenance.
