2 axis horizontal linear guideway lathe(tailstock)
high efficiency! better choice


stuff change
Because of the personnel change. NOW, new person charge the part of lathe and machining center!!!NAME: Klein
EMAIL:zoulongyugz@126.com
PHONE/WECHAT: +86 1338000192
Linkedin: klein klein
WhatsApp: +61 0421165440
Please check it! contact me if you looking for our INF of machine tool part


PRODUCT SPECIFICATIONS


Item
Item
L-3430
L-4050
L-5075
Capacity
MAX. swing diam over. bed
340
400
550
2
MAX.swing diam. over
130
220
250
3
MAX. turning diam
340
400
500
4
MAX. turning length
280
420
750
5
slanting bed angle
45°
spindle
spindle nose
A2-5
A2-6
7
chuck
6‘''
8''
10''
8
spindle bore
56/42
61/49
MAX. spindle speed
4500
4000
feeding axis
X/Zaxis travel
180/330mm
230/500mm
280/750mm
X/Zaxis rapid traverse
24/24m/min
X/Zaxis ballscrew specs
3208/3210
3208/3208
3210/3210
positioning accuracy(JIS）
0.01
repeatability(JIs)
0.007
electrical machinery
spindle motor
3.7/5.5kw
7.5/11kw
X/Zaxis servo motor(FANUC)
1.2/1.2kw
1.8/1.8kw
1.8/1.8kw
coolant motor
0.49kw
tailstock
tailstock travel
270
450
750
sleeve travel
100
100
120
sleeve diam
Φ72
Φ90
tailstock and sleeve taper
MT4
MT5
tool change system
tool changing type
hydraulic turret
turret model
Y130
Y160
Y200
tool capacity
8cutter spacinh
10cuttingspac
OD tool shank
20x20mm
25x25mm
ID tool shank
Φ25mm
Φ32mm
general
power capacity
10KVA
15KVA
ove  alll diemsions
1800x1200x1600
2640x1750x1700
3100x1870x1900
N.W.
2.8T
3.5T
4T


PRODUCT CONFIGURATION


CNC controller
pedestal
hydraulic turret
