Factory outlet gear hob machine Y3150 for sale
- Category: Planer & Slotting Machines >>>
- Supplier: Zaozhuang City Tengdong Machine Co. Ltd.
Share on (1600316460422):
Product Overview
Description
Company Profile
Product Description
Technical specification | |
Max. Workpiece diameter( no rear column/rear column) | 500/350mm |
Maximum modulus (cast iron/steel) | 6/5mm |
Max. Working width | 350mm |
Min number of processed teeth | 5 |
Max vertical stroke of knife rest slide | 300mm |
Max helical Angle of helical gear | ±45 |
Distance from tool center to work surface | 235-535mm |
Spindle taper | MT5 |
Max tool size | ɸ160*160 |
Max axial movement distance of hob | 55 |
Diameter of hob with changable mandrel | 22,27,32mm |
Distance from tool center to table center | 30-330mm |
Hydraulic rapid movement distance of worktable | 50mm |
Worktable outer diameter/table hole diameter | 510/80mm |
Spindle speed steps | 8 |
Spindle speed range | 50-275rpm |
Main motor power | 3kw/1440rpm |
Axial fast motor power | 1.1kw/1410rpm |
Worktable fast motor power | 1.1kw/1380rpm |
Hydraulic pump power | 1.1kw/935rpm |
Weight | 2400kg |
Overall dimensions | 1825*935*1730mm |
Q1: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
Q2.What is your minimum order quantity and warranty?
A:MOQ is one set, and warranty is one year.
Q3.How soon can I receive the goods?
A:Most of our products are in stock, and we will arrange shipment around a week after payment is completed.
Q4.Can I trust you?
A:Sure, we’re Alibaba Gold Suppliers , Alibaba Assessed Supplier , Alibaba Trade Assurance Supplier.
Q5.What is the package? Is it suitable for shipment?
A:Machine is by waterproof cloth to covered.And be packed by standard exported wooden case with steel foot.. It is very much strong for oversea transportation.
Q6.Are you manufacturer?
A: Yes, we are a manufacturer of machine tools,we have our own technical team, and about 100,000 sq.m workshop, welcome to visit us!
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
Q2.What is your minimum order quantity and warranty?
A:MOQ is one set, and warranty is one year.
Q3.How soon can I receive the goods?
A:Most of our products are in stock, and we will arrange shipment around a week after payment is completed.
Q4.Can I trust you?
A:Sure, we’re Alibaba Gold Suppliers , Alibaba Assessed Supplier , Alibaba Trade Assurance Supplier.
Q5.What is the package? Is it suitable for shipment?
A:Machine is by waterproof cloth to covered.And be packed by standard exported wooden case with steel foot.. It is very much strong for oversea transportation.
Q6.Are you manufacturer?
A: Yes, we are a manufacturer of machine tools,we have our own technical team, and about 100,000 sq.m workshop, welcome to visit us!
