Optical Parameter | |
Sensor | SONY 1/2.8" IMX CMOS |
Effective Pixels | 2.07 Megapixels |
Signal System | PAL/NTSC |
Resolution | 1080P60, 1080P50, 1080P30, 1080P25, 1080I60, 1080I50, 720P60, 720P50, 1080I59.94, 720P59.94 |
HOV | 20X:58.7°(W)~3.2°(T) 12X:62°(W)~5.0°(T) 10X:58°(W)~5.8°(T) 3X:90°(W)~30°(T) |
Shortest View Distance | 10mm(W)~1000mm(T) |
Minimum Illumination | 0.1Lux |
Exposure Control | Auto, Manual |
Shutter Speed | 1/1s ~ 1/10,000s, 22 steps |
Gain | Manual |
White Balance | Auto, ATW, Indoor, Outdoor, Manual |
Noise-Signal Ratio | ≥50db |
OSD Menu | Support |
Mechanical Parameter | |
Pan-Tilt | Horizontal Angle: ±170°(Maximum speed: 100°/s) Vertical Angle: -30°to +90°(Maximum speed: 60°/s) |
No. of Preset Positions | 255 |
Video Output Interface | HDMI, HD-SDI(3G), RJ45 |
Control Interface | RS-232C(Mini 8-DIN)(VISCA IN and OUT), RS485 |
Control Protocol | VISCA, PELCO P/D |
Baud Rate | 9600bps, 4800, 2400bps, 115200 |
Video | H.264,H.265 |
Compression Frame Rate | 1920*1080@30fps,1280*720@30fps; 960*540@30fps,640*480@30fps |
Video Compression Rate | 100kbps-8Mbps Continuously Adjustable, Support CBR/VBR |
Data Storage | Video and Photos |
Storage Mechanism | Auto, Manual(Loop, Timing, Motion Detect) |
Protocols | TCP/IP,UDP,RTP,RTSP,RTCP,HTTP,DNS,DDNS,DHCP,FTP, NTP,UPNP,RTMP |
ONVIF | Support |
