Rocware 1080P60 SDI ptz camera 4K 12X Optical zoom PTZ Live streaming camera NDI USB conference camera for live events, podcast

HD: 1080p/60, 1080p/50, 1080i/60, 1080i/50, 1080p/30, 1080p/25, 720p/60, 720p/50, 720p/30, 720p/25
SD: 480i, 576i

1/2.8'', CMOS, Effective Pixel: 2.07M

12x, f3.5mm ~ 42.3mm, F1.8 ~ F2.8

16x

0.5 Lux @ (F1.8, AGC ON)

Auto, 3000K/Indoor, 4000K, 5000K/Outdoor, 6500K_1, 6500K_2, 6500K_3, One Push, Manual

Support

2D&3D Digital Noise Reduction

≥55dB

AAC

96Kbps, 128Kbps, 256Kbps

169mm x 142mm x 164mm

1xHDMI: Version 1.3
1x3G-SDI: BNC type, 800mVp-p, 75Ω, Along to SMPTE 424M standard
1xCVBS: 3.5mm mini jack, 1Vp-p, 75Ω
1xRJ45: 10M/100M Ethernet Interface
1-ch: 3.5mm Audio Interface, Line In
1xUSB2.0: Type A female jack
1xRS232 In: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA/Pelco-D/Pelco-P
1xRS232 Out: 8pin Min DIN, Max Distance: 30m, Protocol: VISCA network use only
1xRS485: 2pin Phoenix Port, Max Distance: 1200m, Protocol: VISCA/Pelco-D/Pelco-P
JEITA type (DC IN 12V)
