Working principle of cement mortar spraying machine
The working principle of the mortar spraying machine is to use air compressor to drive the abrasive (or projectile) to the work piece surface, the surface of the work piece micro-cutting or impact to achieve the work piece rust, paint, Decorative treatment.
|Applicable materials ratio (water, ash, sand)||0.7—1:1:3|
|Main motor power||5.5kw|
|Transport distance||Level 30m vertical 15m|
|Displacement of air compressor||0.3m3/min|
|Maximum aggregate diameter||≤4mm|
|Inner diameter of feeding pipe||32mm|
Cement mortar spraying machine Features
1.The high efficiency mortar spraying machine has a reasonable design, an integrated pump and compressor, and is easy to move.
2.Screw mortar spraying machine continuous feeding without pulse.
3.The mortar spraying machine has a wide range of practicability. It can spray dry powder, mortar, and ordinary mortar.
4.The machine featured with uniform spraying and strong adhesion.
5.The mortar spraying machine is multi-functional device and can be both sprayed or shotcreted.
6.The gun and nozzle connection can be selected in any direction for easy operation.
Cement mortar spraying machine application
1.In the construction engineering industry, the machine is used for horizontal and vertical transferring and spraying mortar or cement.
2. In the chemical and paper industry, delivering the raw pulp material and waste materials.
3. In coal-fired power plants, the machine is used to deliver the fine coal mortar.
4. In the mining tunnel construction industry, the machine is used to grout and protect slope.
5. In the highway pavement maintenance, it used for road surface collapse pressure mud filling.
6. In Prestressing structure construction, the machine is used for cement road surface collapse pressure mud filling.
7. In water conservancy engineering, it is used for reinforcing the dam.
8. In metallurgy, steel and other industry, the machine is used to maintain the blast furnace and slurry infusion of the other equipments.
1. Cement mortar spraying machine Packaging:
1)Wrapped by protective film;
2)Packed by standard import & export wooden cases or carton boxes.
2. Cement mortar spraying machine Shipping:
By logistics; by automobile; by train; by shipping; by air etc.
1.We have more than15 years manufacture and export experience.
2.Exporting to all over the world,win high reputation among customers.
3.CE, ISO 9001 and Strict Production Guideline to guarantee the high quality of our products.
4.Near the Qingdao port convenient for exporting.
5.Customer service staff 24 hours online,offer free technical support.
6.Factory and Competitive Price we offer.
7.Strong Research & Development technical team.
8.Various machinery to meet all your needs at our factory.
9.Engineers are available to guide the installation and take care of other problems.
10.We offer OEM&ODM service to meet all your requirements
