Automatic spray machine for Multicolor spray paint

Stone Paint/Multi-Color Paint Automatic Spraying Machine

Modle		JXLV-SAS-1300	Number	Brand	Origin
Motor		GH-28-750-100-S	1	Haoxin	Taiwan
Servo		ASD-A2-1521-B+ECMA-E11320	1	Delta	Taiwan
PLC		DVP-3200T3	1	Delta	Taiwan
Touch Screen		B07411	1	Delta	Taiwan
variable voltage and variable frequency		VFD007M43B	1	Delta	Taiwan
LWHS		HGH20CCA1R2300ZOC	2	Shangyin	Taiwan
Spray Gun		1500	2	GRACO	America
Screw pump		G35-2-N-V-M103	1	JXY	China
fan		T30-4C-0.75kw	1	POPULA	China
	Maximum Length of workpiece(mm)	3000	Feeding Speed(m)	0~5
	Minimum Length of workpiece(mm)	300	Feeding Style	steel wire rope
	Maximum width of workpiece(mm)	1300	Type of products	Plate workpiece
	Minimum width of workpiece(mm)	500	Application	Calcium silicate board Feber cement press board
	Maximum thickness of workpiece(mm)	80	Water weight of the pressed air	<1.3g/m3
	Minimum thickness of workpiece(mm)	5	Oil weight of the pressed air	<0.0000001g/m3
	Paint	Water based	Enviroment temperature	10℃~30℃
	Pressure	0.6~0.8MPa	Water content of the enviroment	40%~60%
	Flow	2m3/min	Total power(kw)	10

1,This machine suit for intergration of exterior wall thermal insulation decorative painting,such as stone paint,water-in-water ( multi color paint ) and vanish surface.Its characteristics:uniform spray,save paint,high efficiency and save the manpower.

2,Convery system adopts steel wire rope to ensure the back of workpiece not secondary pollution during spraying.And it is easy to clean.

3,The support of spraying gun adopts Two-Way&Two Group style and preset 2 guns system.Stone paint gun adopts GRACO from USA and IWATA from Japan.

4,The drive structure controlled by Taiwan DELTA servo motor to ensure full precision spraying.

5,Machine configuration Taiwan DELTA programmable controller PLC.Located at the inlet of the machine photoelectric scanning system that can automatically detect the length and width of the workpiece,and control the range of movement and spray gun ,to save paint consumption.

6,The oil pipe cycle design to ensure the stable pressure in the spray gun,paint flux adjusts by control valve.

7,Discharge of paint mists adopts Above Let, this not only save space but keep the spraying area clean.

8,With independent research and development of unique practical feeding system,it makes the spray working more stable and easy to operate.

9,380V 50Hz power source and 0.5Mpa air source.

Package

wooden standard carton is suitable for the export and long transportation,free fumigation.

Payment

We usually accept T/T, payment terms : 30% TT deposit, the balance before shipping.

Shipment

Air,sea and express transportation all are available,we have good cooperations with them ,this saves your shipping cost and guarantee your goods safe, if your own forwarder in China can

help you to handle the export ,we can accept the factory price(EXW.),

We arrange the local shipment,which’s easy for you to control the transportation cost.

Warranty

- 1 years warranty for the machines.
- Any warranty shipping cost to us is responsible by buyer

Certification of quality:

FAQ

What is the curtain coating machine for wood floor ,Furniture warranty?

Warranty: Warranty is valid for 12 months in the hypothesis of machinery use for an 8-hour
working shift. Warranty does not cover parts subject to normal wear or damaged by improper
use, incident or negligence of the Buyer or by reasons external to normal use (i.e. change in the
power net, caused by thunderstorm, etc.) Transport costs and labour are excluded.

Have you inspect the finished products?

Yes, Each step of production products will be camed out inspection by QC before shipping.

What’s the delivery time?

Within 25 days after get the payment.
