PCB customized Circuit Board Factory PCB Prototype Board enepig PCB
- Category: Electronic Components, Accessories & Telecommunications >>>
- Supplier: King Field Electronic Co. Ltd.(Shenzhen)
Share on (1600361576827):
Product Overview
Description
Video Description
Welcome to King Field
King Field Electronics(shenzhen) has always been focusing on the design and production of high-end circuit boards, providing customers with professional and efficient one-stop turnkey solutions.
double-sided and multi-layer circuit boards，
HDI high-density boards, IC packaging board,
SMT patch processing services for customers，
ceramicsubstrate, copper substrate, aluminum substrate,
company's main products:
FPC board, Rigid-Flex PCB,
double-sided and multi-layer circuit boards，
HDI high-density boards, IC packaging board,
SMT patch processing services for customers，
ceramicsubstrate, copper substrate, aluminum substrate,
Products Description
RPCB Main Equipment
Rigid RPCB Manufacturing Capability
Rigid RPCB Manufacturing Capability | ||||
Item | RPCB | HDI | ||
minimum linewidth/linespacing | 3MIL/3MIL(0.075mm) | 2MIL/2MIL(0.05MM) | ||
minimum hole diameter | 6MIL(0.15MM) | 6MIL(0.15MM) | ||
minimum solder resist opening (single-side) | 1.5MIL(0.0375MM) | 1.2MIL(0.03MM) | ||
minimum solder resist bridge | 3MIL(0.075MM) | 2.2MIL(0.055MM) | ||
maximum aspect Ratio (thickness/hole diameter) | 10：1 | 8:1 | ||
impedance control accuracy | +/-8% | +/-8% | ||
finished thickness | 0.3-3.2MM | 0.2-3.2MM | ||
maximum board size | 630MM*620MM | 620MM*544MM | ||
maximum finished copper thickness | 6OZ(210UM) | 2OZ(70UM) | ||
minimum board thickness | 6MIL(0.15MM) | 3MIL（0.076MM） | ||
maximum layer | 14层 | 12层 | ||
Surface treatment | HASL-LF、OSP 、Immersion Gold、 Immersion Tin 、Immersion Ag | Immersion Gold、OSP、selectiveimmersion gold、 carbon print | ||
Min/max laser hole size | / | 3MIL / 9.8MIL | ||
laser hole size tolerance | / | 10% | ||
PCB manufacturing | ||||||
Layer | quick turn （hours） | usual time （days） | Mass productions＞30m2 （days） | |||
2 | 24 | ＜4 | ＜10 | |||
4 | 48 | ＜6 | ＜12 | |||
6 | 72 | ＜8 | ＜14 | |||
8 | 96 | ＜10 | ＜16 | |||
10 | 120 | ＜12 | ＜18 | |||
Our Advantages
Certifications
Product packaging
FAQ
1.What does kingfiled need for a customized PCB order?
When you place a PCB order, you need to provide Gerber or pcb file.
If you do not have the file in the correct format, you can send all the details related to the products.
2.What does kingfield need for a customized PCBA order?
When you place a PCBA order, you need to provide Gerber or PCB file and the BOM list.
3.What is your quotation policy?
For the PCB order in large quantity, we will send you the quotation based on the MOQ of the products concerned.
4.What does Kingfield need for other services?
For PCB clone service, the customer needs to send us the printed circuit board concerned, and also the sharp photos of its front side and the back side.
5.How about the service kingfield offered to the customers?
If you have any questions about our products or company, do not hesitate to send us your inquiry to our customer service representatives. Your satisfaction is our pursuits.
6.Do you have the capability of manufacturing high frequency materials? Like Rogers?
We can manufacture these, while expensive,pls just contact us for price prior to place the order.
