SNBC BSC 5060 600DPI 60ppm Batch Scanning Ocr Document Scanner a4 scanning size scanner

Item

BSC-5060

Parameters

Scanning method

Automaticlly feeding and detecting documents

two sided scanning

Scanning component

CIS

illuminant

RGB

Resolution

300dpi,600dpi

Output resolution

100,150,200,240,300,400,600dpi

Others

Gray scale 256,24 natrual color

Automatically skew detecting/adjusting, cutting.

Process to the same size of the original docs.

Scanning speed

gray:60ppm/120ipm(200dpi,A4);

black&white:60ppm/120ipm(300dpi,A4);

color:60ppm/120ipm(200dpi,A4);

color: 40ppm/80ipm(300dpi,A4)

Scanning area

horizontal:50mm~216mm

vertical:50mm~800mm(max: 3000mm)

paper

thickness:0.03---1.25mm

Others

sensor

Top cover up:micro switch

Paper feeding sensor:mechanical photoelectric sensor

Double paper detection:ultrasonic sensor

Paper alignment sensor:transmission photoelectrical sensor

ADF capacity

75 pcs

interface

USB 2.0

Powe supply

24V±5%DC,1.5A

Operating temperature and humidity

5℃~45℃,20%~90%(40℃)

Storage temperature and humidity

-40℃~60℃,20~93%(40℃)

Dimension

312(L)*232.5(W)*209.5(H)

Weight

4.5kg

Software

Driver

USB driver; TWAIN2.1; WIA; ISIS;SANE (Linux System driver)

SDK

SDK (Windows, Linux)
