DD 70mm EDF 11 Blades Ducted Fan with 3400KV RC Brushless Motor Balance Tested for EDF 4S RC Jet Airplane
- Category: >>>
- Supplier: Shenzhen Diamond Dynamics Technology Co. Ltd.
Share on (1600428557966):
Product Overview
Description
DD 70mm EDF 11 Blades Ducted Fan with 3400KV RC Brushless Motor Balance Tested for EDF 4S RC Jet Airplane
Advantages:All the EDF with motor have already dynamic balance tested.Running smoothly,Easy cooling,Stable structure,Safe and durable,excellent realistic sound.Make your plane more Efficient and stable.All the motor has been soldered the banana plug.
Main Parameter: 70mm EDF with 3400KV/4S motor: max continuous current is 75A,max thrust is 1810g.Motor weight 108g.Thus we recommend 80A ESC and 4s battery.
motor:motor Continuous operation, high temperature resistance,wear resistance and stable,it’s more anti-aging and durable.Premium motor provides stable and balanced operation when in continuous working.
High-Quality ducted fan: fan make of high-quality engineering materials,Sturdy body,stable structure.Removable guide ring design,Adapt to a variety of models.
Pure copper wire: strong conductive, fast heat dissipation, high temperature resistant silicone wire.
Advantages:All the EDF with motor have already dynamic balance tested.Running smoothly,Easy cooling,Stable structure,Safe and durable,excellent realistic sound.Make your plane more Efficient and stable.All the motor has been soldered the banana plug.
Main Parameter: 70mm EDF with 3400KV/4S motor: max continuous current is 75A,max thrust is 1810g.Motor weight 108g.Thus we recommend 80A ESC and 4s battery.
motor:motor Continuous operation, high temperature resistance,wear resistance and stable,it’s more anti-aging and durable.Premium motor provides stable and balanced operation when in continuous working.
High-Quality ducted fan: fan make of high-quality engineering materials,Sturdy body,stable structure.Removable guide ring design,Adapt to a variety of models.
Pure copper wire: strong conductive, fast heat dissipation, high temperature resistant silicone wire.
Specification
Material | PA66+GF |
Gold plated connector | Φ3.5 |
KV | 3300 |
Motor Weight | 108g |
Max Voltage | 16.8V |
Max Current | 75A |
Max power | 1638W |
Max Thrust | 1810g |
Recom.Battery | 4s 3500MAH 35C |
Recom.ESC | 80A |
Details Images
Company Profile
Formally established in February, 2021- Shengzhen Diamond Dynamics Technology Co.,LTD specializes in the R&D, production and sales of DC brushless motors, thrusters and intelligent motor control systems.
The mission of Diamond Dynamics is to "Energize the world".
With an innovative spirit, Diamond Dynamics builds high-quality power systems fit for the global market.
Since its establishment, Diamond Dynamics launched core product lines including brushless motors for robotic and RC applications; underwater thrust systems and UAV motor control systems.
Diamond Dynamics products are utilized in a wide range of applications, including but not limited to: marine thrusters, radio controlled models, agricultural/logistics/police/firefighting/surveying and other industrial level drones, light transportation (2 and 4 wheeled), electric boating (lure boats and sightseeing boats), Automobile (cars and buses) and domestic appliances.
The mission of Diamond Dynamics is to "Energize the world".
With an innovative spirit, Diamond Dynamics builds high-quality power systems fit for the global market.
Since its establishment, Diamond Dynamics launched core product lines including brushless motors for robotic and RC applications; underwater thrust systems and UAV motor control systems.
Diamond Dynamics products are utilized in a wide range of applications, including but not limited to: marine thrusters, radio controlled models, agricultural/logistics/police/firefighting/surveying and other industrial level drones, light transportation (2 and 4 wheeled), electric boating (lure boats and sightseeing boats), Automobile (cars and buses) and domestic appliances.
FAQ
Q1: Are you a manufacturer ?
Yes, we are the headoffice & manufacturer of DD brand .
We can do both OEM and ODM. We have our own R&D team.
Q2: What shipping method ?
DHL Express is the default delivery method. It usually takes 5-7 days to get to your location. We accept UPS, FedEx and other ways you need, if you have a forwarder in China, we can also send to your Chinese forwarder
Q3: How is your warranty service?
We do strict test before shipping and guarantee for 365 days. We pay high attention to after-sales service.
Q4: What's of payments method?
We accept Alibaba trade assurance , Paypal , Bank transfer , Credit card .
Yes, we are the headoffice & manufacturer of DD brand .
We can do both OEM and ODM. We have our own R&D team.
Q2: What shipping method ?
DHL Express is the default delivery method. It usually takes 5-7 days to get to your location. We accept UPS, FedEx and other ways you need, if you have a forwarder in China, we can also send to your Chinese forwarder
Q3: How is your warranty service?
We do strict test before shipping and guarantee for 365 days. We pay high attention to after-sales service.
Q4: What's of payments method?
We accept Alibaba trade assurance , Paypal , Bank transfer , Credit card .
