BX RCA hollow flange cycloidal pinwheel precision reducer gearbox Robot joint gearbox

Structure of cycloidal pin gear speed reducer RV-E series consists of main bearing internal mechanism,double reduction gear,double column support mechanism,rollingcontact mechanism and pin gear mechanism.

3F RV-C gearbox is developed for robotic industries.The size of RV-C gearbox is compact and light weight and short dimension could eliminate the inertia of Robot swing to achieve high precise positioning .

RV-C precision reduction gear has excellent accuracy, rigidity, torque, and load sup capabilities.The RV-E series gearbox is highly regarded for its reliability and has the number one market share in the world for precision reduction gears.
