Оригинальный Huawei FusionServer XH321 V6 высокой плотности сервер графического процессора сервера 1U 4 гнезда для стоечных серверов

Item

Value

Model number

XH321 V6

CPU

2/4 Third-generation Intel Xeon scalable processors 6300/8300 series, up to 270W

Memory

Supports 16 2933 MT/s DDR4 DIMMs, up to 1 TB memory capacity (configured with 64 GB DIMMs)
Supports 4 2666 MT/s DCPMMs as volatile or non-volatile storage, which can be used together with 8 DDR4 DIMMs, offering up to 2.5
TB memory capacity (configured with 512 GB DCPMMs and 64 GB DDR4 DIMMs)

Internal Storage

Up to 6 x 2.5-inch SAS/SATA/SSD/NVMe drives or 3 x 3.5-inch SAS/SATA/SSD drives
Up to 2 x M.2 2280 or 2242 SATA SSDs
Support for mixed use of different drive types

RAID Support

RAID 0, 1, 5, 6, 10, 50, or 60; supercapacitor for power failure protection
M.2 SSDs can be used to build RAID 0 or 1

PCIe Expansion

2 PCIe x16 half-height, half-length standard expansion slots

Management

Supports standard management interfaces such as SNMP and IPMI
Provides management features such as virtual KVM, virtual media, SOL, remote control, hardware monitoring, and intelligent power
supply
Supports power capping, independent management network port, and NC-SI management

Operating Temperature

5ºC to 35ºC

Dimensions (H x W x D)

40.5 mm x 177.9 mm x 545.5 mm
