Product Code | T350 | ||||
Processor | One Intel Xeon E-2300 Series processor with up to 8 cores One Intel Pentium processor with up to 2 cores | ||||
Operating System | Canonical Ubuntu Server LTS Microsoft Windows Server with Hyper-V SUSE Linux Enterprise Server Red Hat Enterprise Linux VMware ESXi* * support only from Dec'21. | ||||
Chipset | Intel C256 series chipset | ||||
DIMM Speed | Up to 3200 MT/s Note: For Pentium processor, maximum memory speed supported is 2666 MT/s. | ||||
Memory Type | UDIMM | ||||
Memory Module Slots | 4 DDR4 DIMM slots | ||||
Maximum RAM | UDIMM 128 GB | ||||
Front Bays | Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB Up to 8 x 3.5-inch SAS/SATA (HDD/SSD) max 128 TB (Also supports 2.5-inch drive in 3.5-inch hybrid drive carrier) | ||||
Internal Controllers | PERC H755, PERC H345, HBA355i | ||||
External Controllers | HBA355e | ||||
Software RAID | S150 | ||||
Internal Boot | Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs 240 GB or 480 GB Internal Dual SD Module or Internal USB 3.0 | ||||
Security | Cryptographically signed firmware Secure Boot Secure Erase Silicon Root of Trust System Lockdown (requires iDRAC9 Enterprise or Datacenter) TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ | ||||
Mobility | OpenManage Mobile | ||||
PCIe | 2 x Gen 4 PCIe slots, 2 x Gen3 PCIe slots | ||||
Embedded / At-the-Server | iDRAC9 iDRAC Direct iDRAC RESTful API with Redfish iDRAC Service Module | ||||
Consoles | OpenManage Enterprise OpenManage Power Manager plugin OpenManage SupportAssist plugin OpenManage Update Manager plugin | ||||
Tools | IPMI OpenManage Server Administrator OpenManage Storage Services RACADM CLI System Update Utility Update Catalogs | ||||
OpenManage Integrations | BMC Truesight Microsoft System Center RedHat Ansible Modules VMware vCenter and vRealize Operations Manager |
