special shaped wood straight curve edge bander banding machine
- Category: Wood Based Panels Machinery >>>
- Supplier: Spower Machinery Technology Co. Ltd. (jinan)
Share on (1600520643033):
Product Overview
Description
Product Description
Detailed explanation of operation steps：
The automatic curve edge banding machine is specially designed for edge banding and trimming of wooden boards. The machine consists of an edge banding structure, a trimming machine structure and a vacuum suction cup rotating arm mechanism.
1. Step on the electric foot switch to start the edge sealing operation.
2. During edge sealing, the belt feeding mechanism and the gluing mechanism automatically convey the edge sealing belt, and apply high-temperature hot melt adhesive with a uniform and moderate thickness.
3. Then transfer the coated edge banding tape to the proper position of the edge banding roller, and the automatically rotating edge banding roller and the automatic plate conveying mechanism complete the automatic edge banding together.
4. For finishing, the start and stop of the trimming motor is controlled by operating the compound electric button on the trimming machine.
5. During operation, use the pneumatic foot switch to manually insert the plate to be modified into the upper and lower trimming guide wheels of the trimmer, and complete the upper and lower edge trimming and side action by contacting the edge trimming arc guide plate and the high-speed rotating trimming knife.
The automatic curve edge banding machine is specially designed for edge banding and trimming of wooden boards. The machine consists of an edge banding structure, a trimming machine structure and a vacuum suction cup rotating arm mechanism.
1. Step on the electric foot switch to start the edge sealing operation.
2. During edge sealing, the belt feeding mechanism and the gluing mechanism automatically convey the edge sealing belt, and apply high-temperature hot melt adhesive with a uniform and moderate thickness.
3. Then transfer the coated edge banding tape to the proper position of the edge banding roller, and the automatically rotating edge banding roller and the automatic plate conveying mechanism complete the automatic edge banding together.
4. For finishing, the start and stop of the trimming motor is controlled by operating the compound electric button on the trimming machine.
5. During operation, use the pneumatic foot switch to manually insert the plate to be modified into the upper and lower trimming guide wheels of the trimmer, and complete the upper and lower edge trimming and side action by contacting the edge trimming arc guide plate and the high-speed rotating trimming knife.
Model | XHW-22 | |
The height of the workbench from the ground(mm) | 950 | |
Edge thickness(mm) | 10-60mm | |
Process capability | ||
Rectangular plate | ||
Minimum size | 150*200mm | |
Maximum size | 1220*2440mm | |
When the thickness of the edge banding is 1mm | Rmin=30mm | |
When the thickness of the edge banding is 2mm | Rmin=50mm | |
When the thickness of the edge banding is 3mm | Rmin=80mm | |
Circular plate | ||
Φ min=200mm | Φ Max=2400mm | |
shouldered sole plate | ||
Rmin=250mm | ||
Maximum gravity of plate | 40Kg | |
Working air pressure | 0.6MPa | |
Total power consumption(kw) | 4.5Kw | |
Net weight(kg) | 570kg | |
Overall dimensions(LxWxH) | 2275*1620*1580mm | |
Detailed Images
Fiber Scanning Device
Precise docking,fast speed, high precision, large range, strong electrical interference ability.
Foot Switch
1.Edge banding pedal: Control the cutter cylinder. Press the pedal to operate the cylinder and break the belt.
2.Trimming pedal: Control the opening and closing of the trimming spindle.
2.Trimming pedal: Control the opening and closing of the trimming spindle.
Edge Banding Automatic Control Trigger
During edge sealing, the belt feeding mechanism and the gluing mechanism automatically convey the edge
sealing belt, and apply high-temperature hot melt adhesive with a uniform and moderate thickness.
During edge sealing, the belt feeding mechanism and the gluing mechanism automatically convey the edge
sealing belt, and apply high-temperature hot melt adhesive with a uniform and moderate thickness.
CNC touch screen
easy operation. High-quality display LCD screen,
Acuum suction cup
The suction cup increases wear resistance and is easy to rotate
Trimming structure
complete the upper and lower edge trimming and side action by contacting the edge trimming arc guide plate and the high-speed rotating trimming knife.
Feature:
1.Patented product
2.The body is welded with high quality steel plate
3.The worktable is with special treatment process ,better durability
4.Special plastic pot process makes gluing more uniformly.
Advantages:
1..All the parts are made with fine processing of high-precision CNC Center, and this ensures the long-lasting operation.
2..The strict and elaborate assembly process to ensure each equipment requirement gets to its standard indicator .
Machine function: 1.Patented product
2.The body is welded with high quality steel plate
3.The worktable is with special treatment process ,better durability
4.Special plastic pot process makes gluing more uniformly.
Advantages:
1..All the parts are made with fine processing of high-precision CNC Center, and this ensures the long-lasting operation.
2..The strict and elaborate assembly process to ensure each equipment requirement gets to its standard indicator .
special-shaped edge banding, finishing (seamless interface)
Uses:
Uses:
Used for straight or curved edge banding of plate workpieces in panel furniture production and production
Application
Application plates:
MDF, ecological board, solid wood board, fiberboard,particle board,plywood,integrated board ,three bureau hydrogen amine board,Acrylic board,density board,joinery board,particle board etc.
Applicable edge band type :
Applicable edge band type :
ABS,Melamine,Acrylic,solid wood, PVC, melamine, veneer, etc.
