48v 100ah lifepo4 lithium battery pack for solar energy storage rv camping car off grid
- Category: Batteries >>>
- Supplier: Shenzhen High Power Battery Technology Co. Ltd.
Share on (1600526200880):
Product Overview
Description
48v 100ah lifepo4 lithium battery pack for solar energy storage rv camping car off grid
Specification
Electrical Characteristics | ||
Nominal Voltage | 51.2V | |
Nominal Capacity | 100Ah | |
Minimum Capacity | 100Ah | |
Energy | 5120Wh | |
Cycle Life | >2000 cycles @0.5C 100%DOD | |
Months Self Discharge | <3% | |
Efficiency of Charge | 100% @0.5C | |
Efficiency of Discharge | 96~99% @0.5C | |
BMS Functions | Over charge, over discharge, over current, short circuit and temperature protection | |
Standard Charge | ||
Charge Voltage | 56.8-58.4V | |
Charge Mode | 0.2C to 58.4V, then 58.4V,charge current to 0.02C (CC/CV) | |
Charge Current | 20A | |
Max. Charge Current | 50A | |
Standard Discharge | ||
Max Continuous Discharge Current | 100A | |
Peak Discharge Current | 250A 1-3S | |
Discharge Cut-off Voltage | 40V±0.5V | |
Environmental | ||
Charge Temperature | 0 ℃ to 55 ℃ (32F to 131F) @60±25% Relative Humidity | |
Discharge Temperature | -20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity | |
Storage Temperature | -20 ℃ to 45 ℃ (-4F to 113F) @60±25% Relative Humidity | |
IP Class | IP65 | |
Mechanical | ||
Plastic Case | ABS | |
Approx. Dimensions | 520mm*269mm*220mm | |
Approx. Weight | 40kgs | |
Application
Details Images
Certifications
Company Profile
Shenzhen High Power Battery Technology Co., Ltd
Shenzhen High Power Battery Technology Co., Ltd, is a professional and reliable national Hi-tech enterprise of intelligent and clean energy products and solutions. The Company is located in Shenzhen with factory area over 10000 m² and employees more than 200 people. Our Company has a strong and professional R&D team and a well-equipped laboratory for battery testing.
Our company focuses on the energy field and takes batteries as the core, covering two types of battery systems: Lithium Ion Battery (NMC) and Lithium Ferrous (Iron) Phosphate Battery (LiFePO4). Our Company’s smart energy solutions are widely used in Energy Storage System (ESS), Telecommunication, UPS, Electric Vehicles, Wind & Solar Energy and other industries.
We have always adhered to the concept of innovation and customer-oriented development, environmental protection and green development. We will continuously enhance our innovation ability, outstanding production capacity and increasingly perfect delivery ability to deepen the cooperation with customers all over the world.
Our Main product range:
1. ) 12/24V /48V 6Ah-400Ah LiFePO4 Battery in SLA case for RV/ Solar Energy/Marine/UPS;
2. ) 48V50AH/100AH/200Ah LiFePO4 Battery for Energy Storage and Telecom;
3. ) 5KWH-20KWH Power Wall;
4. ) 4KWH-20KWH All-In-One energy storage system with 3KVA/5KVA Inverter;
5. ) 24V/36V/48V/72V/96V LiFePO4/Li-Ion Battery for low speed vehicles;
6. ) Portable Power Station;
7.) Energy Storage System
8.) Other customized lithium battery pack (OEM/ODM)
9.) Lithium battery cells (Lifepo4 and NMC)
Cycle life 800-2000 times for Li-ion battery, and 3000-5000 times @80% DOD for LiFePO4 battery.
Warranty 1-2 years for Li-ion battery, and 3-5 years for LiFePO4 battery.
Optional functions: CAN / RS485 communication, Heating system, etc.
Our company focuses on the energy field and takes batteries as the core, covering two types of battery systems: Lithium Ion Battery (NMC) and Lithium Ferrous (Iron) Phosphate Battery (LiFePO4). Our Company’s smart energy solutions are widely used in Energy Storage System (ESS), Telecommunication, UPS, Electric Vehicles, Wind & Solar Energy and other industries.
We have always adhered to the concept of innovation and customer-oriented development, environmental protection and green development. We will continuously enhance our innovation ability, outstanding production capacity and increasingly perfect delivery ability to deepen the cooperation with customers all over the world.
Our Main product range:
1. ) 12/24V /48V 6Ah-400Ah LiFePO4 Battery in SLA case for RV/ Solar Energy/Marine/UPS;
2. ) 48V50AH/100AH/200Ah LiFePO4 Battery for Energy Storage and Telecom;
3. ) 5KWH-20KWH Power Wall;
4. ) 4KWH-20KWH All-In-One energy storage system with 3KVA/5KVA Inverter;
5. ) 24V/36V/48V/72V/96V LiFePO4/Li-Ion Battery for low speed vehicles;
6. ) Portable Power Station;
7.) Energy Storage System
8.) Other customized lithium battery pack (OEM/ODM)
9.) Lithium battery cells (Lifepo4 and NMC)
Cycle life 800-2000 times for Li-ion battery, and 3000-5000 times @80% DOD for LiFePO4 battery.
Warranty 1-2 years for Li-ion battery, and 3-5 years for LiFePO4 battery.
Optional functions: CAN / RS485 communication, Heating system, etc.
Product packaging
Shipping and Payment
FAQ
Q1. Do you support OEM/ODM services?
Answer: Yes, of course.
Q2. Can I order samples?
Answer: Yes, we welcome to order samples to test and check the quality.
Q3. Do you have a minimum order quantity limit?
Answer: Yes, we have a MOQ for mass production, which depends on different part numbers. But for sample order which used for sample test and inspection will be no limited.
Q4. Can I print my logo on the product?
Answer: Yes. Please inform us formally before production, and first confirm the design based on our samples.
Q5. Does your battery pack include BMS (Battery Management System)?
Answer: Yes, our battery pack includes BMS, mainly functions are: Over charge, over discharge, over current, short circuit and temperature protection.
Q6. Does your battery pack have B lue tooth?
Answer: Yes, we can make B lue tooth function on the batteries. If you need it, you can to tell before you place order.
Q7. Can your battery charge under 0℃?
Answer: Yes, we can make a heating system on our battery pack if you need. The working temperature will be: charge at -20℃ to 55℃ (-4F to 131F) @60±25% Relative Humidity, and discharge at -20℃ to 60℃ (-4F to 140F) @60±25% Relative Humidity.
Q8. How do you ship the batteries and how long will it take to arrive?
Answer: We can ship the batteries by Sea, by Air and by Express like UPS, DHL, FedEx, etc.
Normally shipping by Sea will take around 45-60 days to arrive; shipping by Air will take around 7-15 days.
Q8. What is your production lead time?
Answer: For battery cells will be around 7-10 days after payment received.
For samples, will be around 20-25 days after payment received.
For bulk orders, will be around 25-35 days after payment received.
Q9. What is your payment method?
Answer: We can accept payment by T/T bank transfer, PayPal, West Union, and Cash.
Q10. Do your battery have communication function?
Answer: Yes, our battery can have communication function. Mainly communication ports are CAN, and RS485.
Q11. What brand of inverter that your battery can compliance with?
Answer: Our batteries can compliance with most of the famous brand inverters, which include: Growatt, Victron, Goodwe, Pylon, Deye, Sofar, LuxPowerTec, MR, Must, SAJ, etc.
Q12. Can your batteries support series and parallels connection?
Answer: Yes, but only our Lead Acid Replacement Series support parallels and series connection, which for 12V batteries will support 4pcs max in series to 48V, and for 24V batteries will support 2pcs max in series to 48V.
For parallel connection we suggest not more than 4pcs.
For such connections need to follow our specification datasheet's instruction.
Answer: Yes, of course.
Q2. Can I order samples?
Answer: Yes, we welcome to order samples to test and check the quality.
Q3. Do you have a minimum order quantity limit?
Answer: Yes, we have a MOQ for mass production, which depends on different part numbers. But for sample order which used for sample test and inspection will be no limited.
Q4. Can I print my logo on the product?
Answer: Yes. Please inform us formally before production, and first confirm the design based on our samples.
Q5. Does your battery pack include BMS (Battery Management System)?
Answer: Yes, our battery pack includes BMS, mainly functions are: Over charge, over discharge, over current, short circuit and temperature protection.
Q6. Does your battery pack have B lue tooth?
Answer: Yes, we can make B lue tooth function on the batteries. If you need it, you can to tell before you place order.
Q7. Can your battery charge under 0℃?
Answer: Yes, we can make a heating system on our battery pack if you need. The working temperature will be: charge at -20℃ to 55℃ (-4F to 131F) @60±25% Relative Humidity, and discharge at -20℃ to 60℃ (-4F to 140F) @60±25% Relative Humidity.
Q8. How do you ship the batteries and how long will it take to arrive?
Answer: We can ship the batteries by Sea, by Air and by Express like UPS, DHL, FedEx, etc.
Normally shipping by Sea will take around 45-60 days to arrive; shipping by Air will take around 7-15 days.
Q8. What is your production lead time?
Answer: For battery cells will be around 7-10 days after payment received.
For samples, will be around 20-25 days after payment received.
For bulk orders, will be around 25-35 days after payment received.
Q9. What is your payment method?
Answer: We can accept payment by T/T bank transfer, PayPal, West Union, and Cash.
Q10. Do your battery have communication function?
Answer: Yes, our battery can have communication function. Mainly communication ports are CAN, and RS485.
Q11. What brand of inverter that your battery can compliance with?
Answer: Our batteries can compliance with most of the famous brand inverters, which include: Growatt, Victron, Goodwe, Pylon, Deye, Sofar, LuxPowerTec, MR, Must, SAJ, etc.
Q12. Can your batteries support series and parallels connection?
Answer: Yes, but only our Lead Acid Replacement Series support parallels and series connection, which for 12V batteries will support 4pcs max in series to 48V, and for 24V batteries will support 2pcs max in series to 48V.
For parallel connection we suggest not more than 4pcs.
For such connections need to follow our specification datasheet's instruction.
