Android 11 OS Handheld PDA long range EX30 scanner 20m reading with full alpha numeric keyboard data collector

Share on (1600535132597):


Price:$675.00 - $690.00

Quantity:


Product Overview

Description



Product Description


Android 11 OS Handheld PDA long range EX30 scanner 20m reading with full alpha numeric keyboard data collector


MobileX's MX6100 is an Android-based rugged mobile computer. Built with Android 9 / 11 OS Octa-Core
processor, it supports 27 keys / 37 keys / 47 keys optional keypad, abundant accessories like trigger handle, and features
powerful removable battery. And it delivers optional barcode scanning(20m long range supported), RFID, NFC, etc. This mobile computer can fulfill
applications in logistics, warehousing, retail, etc


OS
Android9.0/Android 11.0 OS
SDK
Free Java Software Development Kit Eclipse / Android Studio and free technical support
CPU/Memory
Android 9:  Snapdragon 450 Octa-core, 1.8 GHz
Android 11: Snapdragon 662 Octa-core, 2.0 GHz
Display
4'' inch  high definition display, TN α-Si 800*480
BT
Android 9: BT4.2/4.1+HS/4.0/3.0+HS/2.1+EDR
Android 11: BT 5.1
GSM/4G/GPRS
2G (GPRS),3G (WCDMA,CDMA,TD-SCDMA),4G (TDD-LTE,FDD-LTE),Depending on ISPs
GPS
GPS/A-GPS
Dimensions
157.6 x 73.7 x 29mm/6.2x2.9x1.1in
UHF
865-868 MHz / 920-925 MHz / 902-928 MHz
Battery
6700 mAh removable main battery, 5200 mAh optional
pistol battery, support QC3.0 and RTC
Camera
13MP autofocus camera with flash
Interfaces/Sensor
USB Micro-B, OTG
1D Linear Scanner
1D Linear Scanner;N4313;UPC/EAN, Code128, Code39, Code93, Code11,
1D Symbologies;Interleaved 2 of 5, Discrete 2 of 5, Chinese 2 of 5, Codabar, MSI, RSS, etc.
2D scanner
Zebra: SE4710/SE4750SR/SE4750MR/SE4750DP/SE4850;
Honeywell: N6603/EX30(long range 20m scanning)
PDF417, MicroPDF417, Composite, RSS, TLC-39,Datamatrix, QR code,Micro QR code, Aztec
HF RFID Reader
Frequency:13.56MHz;Protocol;ISO14443A/B, ISO15693;Chips;M1 card(S50/S70), M0(Ultralight);M3(Desfire D40/D41/D81), CPU_A card
CPU_B card;ICODE II, TI2048, LRI64K;Others for customization;Range:3cm~8cm
NFC
Frequency:13.56MHz; Protocol:ISO/IEC 18092 (ECMA 340); ISO/IEC 21481 (ECMA 352); Range: 2cm~4cm
Accessories
Standard Accessories:AC adapter, snap-on, USB cable;


Products Show










Our Company


Factory

Our Factory

Workshop

Our Workshop



Warehouse

Our Warehouse

Team

Our Team





Our Certifications




FAQ


Q: Are you trading company or manufacturer ?

A: We are handheld mobile computer manufacturer



Q: How long is your delivery time?

A: samples order:3-5 working days.

Bulk order:10-20 working days.



Q: Do you provide samples ?

A: Yes, the sample order is available before bulk order.



Q: What is your terms of payment ?

A: Samples order:100% TT.

Bulk order:30% pepayment start production,70% balance before shipping.



About US


MobileX put the technology innovation and customer value as the core for many years in order to win the competition in the market home and abroad. we are in charge of solving the technical difficulties and give guides for the hardware designs, background software programs.

With the core value of Customer Supreme, Staff Value, Team Work, Result First, MobileXer is shouldering the mission of on-site Management and Mobile Payment Experts to elevate customers' value by scientific management and good service and finally realize our enterprise prospect "Chinese First Brand of Mobile data collection and Application Solution " Currently,we have more than 125 employees,R&D stuff more than 20.And have long cooperation relationship with our OEM factory which in Shenzhen as well."Innovation" is the label of our staff members. We have a professional and experienced technical development group. The members of this group have been improving product quality and trying to develop new products with the latest technology. Definitely we can provide powerful and timely support for technical issues and further development. Meanwhile, we design and make our products according to customers' specifications or requests. ODM&OEM orders are welcome!

"Quality" is the final quest of our members. All our products must be 100% tested to ensure their functionality, reliability, security and durability before shipment. During the past few years, our No.1 priorities have always been customer service and customer satisfaction. We have done a lot to raise quality levels. We are striving to establish a sound quality management and guarantee system.

We are increasingly expanding our international market share based on quality products, excellent service, reasonable price and timely delivery. Selling well throughout the domestic market, our products are also warmly welcomed by clients in Japan, India, South Africa, Brazil, the UK, America, Mexico, Peru and so on. We are looking forward to cooperating with more clients worldwide for common development and mutual benefits.





Service after sales


Thank you for the interest about our products,we will handle the service after sale as following:

1).We offer 1 year warranty,any terminals with quality issue(Exclude human factors) can get

repaired or replacement from us during this period.

2).If clients handle the service locally,we will free offer 1% complete units as spare terminals,2%

LCD,Housing and keyboard.1% other spares.All the quality issue terminals should take picture

and be reported,we will supply it if our spare parts is not enough.

3).For the product maintenance,we will send the video for your reference.If necessary,we will

send technical staff to train client's repairer for free.

4).Wewill provide technical assistance for the whole life.

In case clients would like to extend 1 year warranty period in their market,we would suggest

clients buy 2.5% terminals for replacement.And 2% LCD,Housing and keyboard.1% other spares.
