Product Overview

Description



Company views and introduction as following:
NINGBO GOOD WATER SOURCE ENVIRONMENTAL PROTECTION ELECTRICAL APPLIANCE CO.,LTD
is a export oriented manufacturer of desktop water cooler, mini water cooler, wall-mounted instant boiling water heater, water purifier bottle, water pitcher, etc
The company covers the land area of above 10000 square meters. It enjoys favourable geographical location and convenient transportation.
The company is with different products equipment and different products lines. It has been ISO9000 certified and also has completed R&D, quality control, sales and after-sales service system, etc. The filters inside the products in compliance with NSF standard 42. We also have our own filter lab to test the filters function. The filters inside our products are with high temperature disinfection, ultrasonic welding, UV disinfection and all the test parameters are in compliance with drinking water criterion.
Our goals are Quality leads to market and improvement leads to progress,Attitude is everything, detail is everything, Take science and technology as motive force, live with quality, Customer is our god, quality is god's requirement
We are in line with "quality innovation to win the market, the good faith management cast the future." philosophy, rigorous and meticulous work style, high cost-effective products, try our best to build up domestic packaging materials of the first-class brand. We are willing to make the friend and sincere cooperation, create brilliant with all over the world!

Hope we have a good business cooperation start between us!



Product Description




Specification


item
value
Place of Origin
China
Zhejiang
Brand Name
GWS
Model Number
2208
Dimensions (L x W x H (Inches)
11.5 x 17.8 x 21.70( inches)
Housing Material
Plastic
Power (W)
510W
Voltage (V)
220-240V
After-sales Service Provided
Free spare parts
Warranty
1 Year
Type
Hot & Cold
Installation
Desktop
Application
Hotel, Outdoor, Garage, Commercial, Household
Power Source
Electric
App-Controlled
NO
Private Mold
Yes
Product name
desktop water cooler POU water dispenser
Material
glass, plastic, metal
function
hot, cold , normal
color
to be customized based on the customer's requirement
Style
desktop
rated voltage
220-240V
frequency
50-60Hz
electric shock resistance
I
Enter water pressure
0.1-0.4 Maps
Rated total net water capacity
2000L


Packing & Delivery


Carton packaging


Company Profile




Product Features
This machine is a fully automatic drinking water machine. After installation, the user only needs to open
the water source switch to realize the automatic water production function. Pls make sure that there is
pure water source supply before installation




Main Technical Parameters
Rated Voltage /frequency:220-240 V~50/60 Hz
Electric shock resistance:Ⅰ
Rated Power:510 W
Rated Heating Power:420 W
Rated Cooling Power:90 W
Inlet Water Pressure:0.1—0.4 Mpa
Cooling Capacity:≤10℃,2L/h
Heating Capacity:≥90℃, 5L/h
Proper temperature:10℃—43℃
Power consumption:1.5kW·h/24h
Freezing Medium:R134a/32g
Climate Type:T
Water/Temperature:Municipal water /5—38℃
Relative humidity :≤90%




Installation, Commissioning and Use
The installation method of this machine should be selected according to the actual situation in your
kitchen. The host can be placed around the wall about 15cm, as shown in the figure below (pictured); the
installed room should have floor drain.
★Installation
1. First check the inlet water pressure. If the inlet pressure is greater than 0.4Mpa, a pressure reducing
valve must be installed at the pipeline position. 2. Prepare the necessary installation tools and installed accessories, determine the installation location;
install the three way valve, and the main unit. 3. Install the PE pipe in the following parts according to the process flow: (Figure 3)
★Commissioning and Use
1. Pipeline inspection: After the machine has been producing water for 30 minutes, check the parts and
pipelines for water leakage and water seepage. 2. Finish the pipeline: organize and fix the various installation pipelines, and then clean the installation
site. 3. This machine is controlled by the opening and closing of the mechanical float valve. Normal use is as
convenient and safe as using tap water. 4. Open the water ball valve, the straight drink machine starts to produce water, plug the plug into the
220V ~ 50/ 60Hz power supply, at this time the power light is on, and the hot water tap can release the
water before the heating switch and the refrigeration switch can be turned on. After the heating switch is
turned on, the red light is on and the heating starts. When the red light is off, the heating is completed. At
this time, the water temperature is above 90 °C, and hot water is available. Turn on the cooling switch, the
blue light is on, and the cooling water starts. When the water temperature is less than 8 °C, the blue light
is off to indicate that the cooling is completed and the cold water is available.



Maintenance




Precautions:
▲The inlet pressure must be tested before installation. If the water pressure is higher than 0.4Mpa, the
pressure relief valve must be installed at the inlet end.
▲The inlet pipe must be installed on the cold water pipe, and the inlet water temperature should not
exceed 38 °C.
▲Do not fold or fold the water inlet and outlet pipes, so as not to affect the water flux, resulting in the
machine not working properly.
▲Do not disassemble the parts on the machine to prevent leakage or damage to the machine.
▲ Close the inlet ball valve before going to bed at night or when leaving for a long time during the day.
▲This machine is forbidden when the inlet water temperature is below 5 degrees Celsius.
▲Close the water valve when you are not using it for a long time.
▲When no one is in the house, please turn off the water source and power supply. This product is for
indoor use only.
▲The power cord of this product is connected to the Y-type connection. The power cord can only be
replaced by a professional. Do not replace it yourself.



Warning:
1.Never let infants and children approach or operate the unit! ! In case of any accident!
2. The water ball valve must be closed before going to bed at night or when leaving home during the day!
Water hammer is used to impact the filter element to cause damage and water leakage.
3. When the machine fails, you must quickly turn off the water source and power supply, and notify the
dealer to assign a professional to troubleshoot. 4. Do not replace the filter elements at all levels, and should be carried out by professionals to avoid water leakage



RO system equipment as following:
Product Features
This machine is a fully automatic straight drink machine. It is equipped with a 5-stage filter. It is equipped with a 2 gallons3 / 8pressure tank. After installation, the user only needs to connect the water source and plug in the power supply to realize the automatic water production function. Using RO membrane technology, the treatment process is pure physical filtration principle, without adding any chemicals, chemical changes and chemical reactions, purified water can be directly consumed. After the water tap of the normal temperature is turned on, the red light is turned on after the red switch is turned on, the RO water system starts working, and the UV sterilizer is energized. When the cold water is full, the water system stops working, the green switch is turned on, the blue light is on, and the light starts. Refrigeration, when the water temperature is lower than 10 ° C, the blue light is extinguished to indicate the heat preservation state, and the cold water can be poured. ☆ Polypropylene melt blown filter (PP): It can effectively remove visible objects larger than 5 microns in water. ☆UDF/GAC filter: It can absorb the chlorine, organic chemicals, odor;
☆ Granular activated carbon filter (CTO): It has high adsorption capacity and can remove the color and odor in water. ☆RO membrane filter (RO): Reverse osmosis membrane filter (RO): the application of reverse osmosis principle, intercepting harmful substances in the water, the effluent is pure water; at the same time, the harmful substances are
discharged into the water purifier through the concentrated water outlet. ☆ Rear activated carbon filter (T33): More thorough adsorption of the color and odor in the water purifier, adjust the taste
of pure water, to ensure that the effluent water is sweet and delicious. This series of drinking fountains is elegant and solemn, leading the trend of the times, safe and energy-saving, large amount of hot water, wading parts using food-grade materials, drinking water is safer, municipal water is used as raw water, after filtration, the water quality is in line with "life drinking" Water quality processor health safety and function evaluation specifications - reverse osmosis treatment device (2001) requirements, applicable to units, hotels, office buildings, schools,entertainment and other places.







Components
Components:
1, the panel box 2, the panel 3, the top cover 4, the water box 5, the water box cover 6, the lamp shade 7, the water
tap 8, the fixed plate 9, the switch board 10, the water drain plate 11, the drain joint 11, the float ball 11, the filter
cartridge box, the silicon tube tube, the circuit board, the hot tank, the cold tank, the foam, the foam, the
temperature control, the silicon carbide tube, the pressure type temperature control, the heating switch, the cooling
switch. Power line 27, condenser 28, water inlet connector 29, waste water connector 30, filter 31, compressor 32, drain pipe 33, air pipe 34, left plate 35, right plate 36, bottom plate 37, middle plate 38, cover 39, sealing ring 40, transformer 41, filter element clip 42, pp43, cto44, RO membrane 45, t3346, door 47, water pump 48, waste water valve 49, water inlet valve



Installation diagram
1, main unit 2, bracket 3, self-tapping screws 4, expansion screws


Installation, Commissioning and Use
The installation method of this machine should be selected according to the actual situation in your kitchen. The host can
be placed around the wall about 15cm, as shown in the figure below (pictured); the installed room should have floor drain. ★Installation
1. First check the inlet water pressure. If the inlet pressure is greater than 0.4Mpa, a pressure reducing valve must be
installed at the pipeline position. 2. Prepare the necessary installation tools and installed accessories, determine the installation location, install the water
inlet tee, and the main unit. 3. Install the PE pipe in the following parts according to the process flow: (Figure 3) ◆Between the inlet ball valve and the PPF filter
★Commissioning and Use
After the correct installation, the filter elements of each level should be cleaned as follows:
1. Pull out the T33 filter outlet from the main unit, connect the extension pipe to discharge, open the inlet ball valve, and
rinse the filter elements in turn; repeatedly rinse until the water is clear and no color, then pull out the original pipe. 2. Pipeline inspection: After the machine has been producing water for 30 minutes, check the parts and pipelines for
water leakage and water seepage. 3. Finish the pipeline: organize and fix the various installation pipelines, and then clean the installation site. 4. This machine is controlled by the opening and closing of the mechanical float valve. Normal use is as convenient and
safe as using tap water. 5. Open the water ball valve, the straight drink machine starts to produce water, plug the plug into the 220V ~ / 50Hz
power supply, at this time the power light is on, wait for the hot water tap to release the water to open the heating switch
and the cooling switch, after turning on the heating switch, the red light is on, Indicates heating, red light extinguishes to
indicate heat preservation. At this time, the water temperature is above 90 °C, you can use hot water to turn on, turn on the
cooling switch, blue light or green light is on, start cooling water, water is less than 10, blue light is off, it means heat
preservation, you can pour Use with cold water.Main Technical Parameters
Rated Voltage /frequency:220 V-240V~50-60 Hz
Rated Power:510 W
Electric shock resistance:Ⅰ
Enter Water Pressure:0.1-0.4 Maps
Rated Total Net Water Capacity:2000 L
Water flow:11.7 L/h
Heating Capacity:85℃-95℃,5L/h
Heating Power:420W
Cooling Capacity:≤10℃,2L/h
Cooling Power:90W
Freezing Medium :R134a/32g
Power Consumption:1.3kW•h/24h
Climate Type:T
Water/Temperature: Municipal tap water/5—38℃





Maintenance
In order to ensure that the filter elements at all levels fully play their respective roles, while ensuring that the effluent water
quality meets the standard, the user should periodically replace the filter element;
The user can estimate the replacement cycle according to the following schedule



Components
work life
The water intake of the machine is treated according to the required municipal tap water. However, the water quality of tap water varies greatly from place to place. The water quality varies from season to season. In addition, the daily water consumption of
different families varies widely. Therefore, it should be based on the actual use and experience of the family to determine the
specific replacement cycle.
PPF
3 months
UDF
6 months
CTO
6 months
RO
24-36 months
T33
12  months


Precautions

▲The inlet pressure must be tested before installation. If the water pressure is higher than 0.4Mpa, the pressure relief valve
must be installed at the inlet end.
▲The inlet pipe must be installed on the cold water pipe, and the inlet water temperature should not exceed 38 °C.
▲Do not fold or fold the water inlet and outlet pipes, so as not to affect the water flux, resulting in the machine not
working properly.
▲Do not disassemble the parts on the machine to prevent leakage or damage to the machine.
▲ Close the inlet ball valve before going to bed at night or when leaving for a long time during the day.
▲This machine is forbidden when the inlet water temperature is below 5 degrees Celsius.
▲Close the water valve when you are not using it for a long time.
▲When no one is in the house, please turn off the water source and power supply. This product is for indoor use only. ▲The power cord of this product is connected to the Y-type connection. The power cord can only be replaced by a professional. Don't replace it yourself


When the filter cartridge needs to be replaced, it is recommended that you contact your local dealer for replacement or
repair. Do not operate by yourself! ! !
In order to avoid water leakage accident caused by improper operation, causing unnecessary losses.



Packing List
1. Host 1 set
2. Self-suction head 1
3. Expansion screw 2 sets
4. Instruction manual / Warranty card 1
5. Certificate 1 Sheet
6. PE tube 5 meters
This product is guaranteed for one year, and normal consumables (filters, filter materials) are not guaranteed. For
non-family use of the purchased products, the warranty period for the whole machine and main components is 6 months, unless otherwise specified in the purchase and sale contract.
※ The warranty conditions for the price reduction of the products sold by the factory and commercial units are the same
as above, and the price reduction parts are not guaranteed.
※ The following conditions are not covered by the free warranty, but the company still provides customers with a
fee-based repair service. -- Users are damaged by handling, installation, use, maintenance, improper storage and disassembly;
--There is no valid purchase invoice;
-- Failure to comply with the requirements of the product manual;
-- Damage caused by force majeure;
-- Beyond the warranty period;
-- Because the environmental conditions of the water purifier, such as power supply voltage, water quality, raw water
temperature, ambient temperature, relative humidity, etc., are not controlled by the company, or all losses caused by
non-compliance with relevant national standards and damage, not covered by the free warranty. Tips: The outer packaging material can be recycled; the inner packaging foam is non-degradable material, please sort it! Or
contact the recycling center.
Warning !!!
1. Never let infants and children approach or operate the unit! ! ! In case of any accident!
2. The water ball valve must be closed before going to bed at night or when leaving home during the day!
Water hammer is used to impact the filter element to cause damage and water leakage. 3. When the machine fails, you must quickly turn off the water source and power supply, and notify the
dealer to assign a professional to troubleshoot. 4. Do not replace the filter elements at all levels, and should be carried out by professionals to avoid water leakage




Package shown on the left
