Китай SDLG дорожное оборудование G9200 200hp автогрейдер строительная техника
- Category: Motor Graders >>>
- Supplier: China Construction Machinery Co. Ltd.
Share on (1600547226122):
Product Overview
Description
Specification
Base operating standard | 8975 x 2710 x 3240 mm |
Base operating weight | 15 800 kg |
Blade height | 635 mm |
Blade length | 3 962 mm |
Blade thickness | 22 mm |
Blade tilt backward | 5 |
Blade tilt forward | 47 |
Drive | Hydraulic torque converter |
Drive tanderm total oscillation | 15 |
Engine make & model | BF6M1013EC |
Front axle oscillation | 16 |
Front wheel lean | 18 on each side |
Fuel tank capacity | 270 L |
Full height cab including ROPS | 3 240 mm |
Maximum blade lift above the ground | 445 mm |
Maximum speed (km/hour) | 38 fwd / 23 rev |
Maximum steering range | 50 left / right |
Maximum torque (VT - variable torque) | 710 Nm @ 1 500 rpm |
Minimum turning radius | 7 600 mm |
Net flywheel power (SAE J1349) | 146 kW @ 2 200 tr/min |
No. of gears | 6 fwd / 3 rev |
Operating weight including standard front dozer | 16 800 kg |
Operating weight including standard middle ripper | 16 630 kg |
Operating weight including standard rear ripper (including front block counter weight) | 17 550 kg |
Overall length with ripper & push plate | 10 350 x 2 710 x 3 240 mm |
Shoulder reach outside wheels straight frame (left/right) maximum to right | 2 172 / 2 162 mm |
Transmission type | Fixed shaft power shift |
