High efficiency Bin Cleaner Garbage Collection Truck
- Category: >>>
- Supplier: Hubei Xindongri Special Vehicle Co. Ltd.
Share on (1600548958688):
Product Overview
Description
Specification
Vehicle Parameter： | ||
Product Name | Compactor Garbage Truck | |
Model | YZR5160ZYST5 | |
Chassis No. | EQ1140 | |
Driving Type | 4*2 | |
Gross Weight | 15800kg | |
Related Loading Mass | 6105kg | |
Curb Weight | 9500kg | |
Dimension | 8710*2500*3300mm | |
Wheelbase | 4500（mm） | |
Front Axle Loading Capacity | 5000kg | |
Rear Axle Loading Capacity | 10000kg | |
Approach angle | 23° | |
Departure angle | 14° | |
Front Suspension | 1440mm | |
Rear Suspension | 2770mm | |
Tire | 10.00-20,6+1 PCS | |
Max Speed | 90 (Km/h） | |
Engine parameters: | ||
Model | B190-33 | |
Horse Power | 190hp | |
Displacement | 6700cc | |
Emission Standard | Euro 3 | |
Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling) | |
Gear Box | ||
Gear Box | 8 forward and 1 reverse | |
Superstructure Parameter： | ||
Tank Volume | 12CBM | |
Tank Shape | Arc-shape | |
Tank Material thickness | Bottom:5mm Side:4mm | |
Tank Material | T420（Special Steel） | |
Compression Ratio | ≥2.5 | |
The effective volume of the bucket | ≥0.8m³ | |
Loading cycle time | ≤40 s | |
unload garbage time | ≤45s | |
control method | Automatic、Manual | |
Maximum pressure of hydraulic system | 20MPa | |
Control System | Siemens PLC | |
Engine power control | Fully automatic control | |
Tumbler mechanism | 240L Garbage bin（Others Optional） | |
