Noise Cancelling Touch Screen Tube Desktop Network Conference Chairman Delegate Mic with Voting Function
- Category: >>>
- Supplier: Guangzhou DSPPA Audio Co. Ltd.
Share on (1600577008651):
Product Overview
Description
Details Images
Features
●Adopting network protocol transmission, not compressed
●Powered by system host or normal switch
●2.42 inch OLED screen display
●With audio output interface and volume adjustment
●Connected via network cable
●Chairman mic with priority function
●Powered by system host or normal switch
●2.42 inch OLED screen display
●With audio output interface and volume adjustment
●Connected via network cable
●Chairman mic with priority function
Product Paramenters
Model | D7121 / D7122 | ||
Structure Type | Desktop | ||
Effective Frequency Range of Gain Limit (±3dB) | MIC A to MIC B | 50Hz-14kHz | |
Host LINE to MIC | 30Hz-18kHz | ||
MIC to Host LINE | 40Hz-16kHz | ||
Speaker Power | 1.5W | ||
Static Power Consumption | <6W | ||
Maximum Power Consumption | 8W | ||
SNR | >75dB | ||
Crosstalk Attenuation | >80dB | ||
Harmonic Distortion | <0.5% | ||
Headset Output | 9dBu, 8-32Ω, 3.5mm | ||
Working Power | Host +48V power supply or +48VPoE Switch power supply | ||
Unit Interface | Network interface | ||
MIC | Microphone Type | Electret cardioid condenser | |
Sensitivity | -30dBV/pa | ||
Input Impedance | 2kΩ | ||
Equivalent Noise | 20dB(SPL) | ||
MAX. SPL. | 125dB(THD<3%) | ||
Package Dimensions | 485×280×120mm(2 PCS/Per Carton) | ||
Machine Dimensions | 175×133×46mm | ||
Gross Weight | 2.4 kg | ||
Net Weight | 0.62 kg | ||
