Paperless Motorized Ultra thin HD pop up screen office room audio video system vertical lcd hidden table monitor with microphone
- Category: >>>
- Supplier: Guangdong Baolun Electronics Co. Ltd.
Share on (1600596634026):
Product Overview
Description
Products Description
The product adopts intelligent control technology, taking intelligent terminal as application concept, adopting original guide rail design. One key operation can automatically complete starting, LCD screen up, elevation and other actions, beautiful desktop, space-saving as the purpose, easy to use. With anti-theft, anti-dust, beautify desktop and other function. It can be widely used in conference, office hotel, teaching studio and other occasion, to meet the customer systems development diversity, and office automation environment demand. It is one ideal assistant of your office and teaching.
Features
* With ultra-thin HD touch screen and lifter integrated design, no exposed cable, no connection backboard, no exposed screws, ensure a nice overall appearance of touch display screen.
* Built in an elevating microphone, microphone up and down with automatic straightening function, when MIC bending, it will be automatically straightening when machine close, won’t be damaged.
* Equipment use all-aluminum structure, high-quality aluminum with CNC carved processing, display frame and chassis are made of aluminum alloy, to make equipment refined, lightweight, beautiful.
* Equipment surface treatment is anodized, bright color.
* Equipment panel thickness of only 3mm, width of only 70mm, small footprint.
* Adopt imported steel wire, cooperated with high precision guide rail and linear bearing, AC geared motor as driving force, reduce noise to minimum.
* 15.6-inch ultra-thin LCD touch screen display, resolution up to 1920*1080P, clear and bright display, adjustable backlight design, to prevent fatigue caused by too bright or too dark.
* Support HDMI and VGA two channel signal input, when there is only one signal input, the screen will automatically recognize this signal, when these two signal input at the same time, can be manually switched from panel key, when no signal input, the screen will automatically enter into power saving mode.
* The device can be centrally controlled through central control software, can be controlled by the host computer, one key can make all device in the room go up or down.
* Built-in loop-through output power outlet, can power supply to the terminal to reduce terminal power outlet wiring, make project site wiring more neat and beautiful.
* With USB port on the desktop panel, the user can read the file in the USB or upload files to the USB.
* Built in an elevating microphone, microphone up and down with automatic straightening function, when MIC bending, it will be automatically straightening when machine close, won’t be damaged.
* Equipment use all-aluminum structure, high-quality aluminum with CNC carved processing, display frame and chassis are made of aluminum alloy, to make equipment refined, lightweight, beautiful.
* Equipment surface treatment is anodized, bright color.
* Equipment panel thickness of only 3mm, width of only 70mm, small footprint.
* Adopt imported steel wire, cooperated with high precision guide rail and linear bearing, AC geared motor as driving force, reduce noise to minimum.
* 15.6-inch ultra-thin LCD touch screen display, resolution up to 1920*1080P, clear and bright display, adjustable backlight design, to prevent fatigue caused by too bright or too dark.
* Support HDMI and VGA two channel signal input, when there is only one signal input, the screen will automatically recognize this signal, when these two signal input at the same time, can be manually switched from panel key, when no signal input, the screen will automatically enter into power saving mode.
* The device can be centrally controlled through central control software, can be controlled by the host computer, one key can make all device in the room go up or down.
* Built-in loop-through output power outlet, can power supply to the terminal to reduce terminal power outlet wiring, make project site wiring more neat and beautiful.
* With USB port on the desktop panel, the user can read the file in the USB or upload files to the USB.
Specification
Model | TS-F156MT3 |
Touch Screen | Support |
Lifting time | 28S |
Elevation Angle | 0-30° |
Case Size | 540*60*647mm |
Panel Size | 555*70*3mm |
The lifting hole size | 388*21.5mm |
Desk cut-out size | 542*62mm |
Panel Chimtay Size | 556*71*3mm |
Working Environment | -20℃～50℃，relative humidity≤70% |
Screen Size | 15.6" |
Screen aspect ratio | 16：9 |
Resolution | 1920*1080 |
Video Port | 1 VGA、1 HDMI |
Control Port | 2 groups of 232/485 input and output ports to control microphone and screen lifting, support hand-by-hand connection, 1 USB port for switch on and off, 1 USB port for data transmission |
Microphone interface | Aviation 6 pin interface, support hand-by-hand connection |
Mic rod length | 415mm |
Backlight type | WLED,15K hour，with LED driver |
Contrast | 600：1 |
Brightness | 300cd/㎡ |
Viewing Angle | 45/45/20/40(Typ.) |
Screen Thickness | 9.7mm |
Power Suppply | AC 220V 50-60/HZ |
Power Consumption | 25W |
Weight | 12Kg |
