High speed pcb layout design service
- Category: PCB & PCBA >>>
- Supplier: Shenzhen Anlida Electronics Technology Co. Ltd.
Share on (1600626486365):
Product Overview
Description
Product Description
Shenzhen high speed pcb layout design service
We have a professional team for PCB Layout with average experience more than 10 years.
Proficient in using a variety of EAD tool software, such as: Cadence Allegro, Mentor Graphics , Altium Designer ,Zuken CR5000, Kicad , EAGLE , Proteus etc.
Realize the mutual conversion among the schematics and PCB original files designed by of a variety of software,
- High-quality professional engineers, engineers with average experience more than 8 years, senior engineers with experience more than 20 years.
- Packaging engineer, Layout engineer, SI engineer, EMC engineer, DFM engineer... the guarantee of profession
- Process first, large-scale team, dedicated technology...the greatest guarantee of quality.
- PCB design, farication, assembly, fast response...the maximum guarantee of delivery time.
Please send schematic (Any format) to me, I will quote you the price.
Company Introduction:
| All Services: |
| - High-Speed PCB Design / PCB Layout |
| - High-Speed PCB SI / PI / EMC Analysis |
| - PCB Reverse Engineering Design, Engineering and Early Design-in Support |
| - PCBA Reverse Engineering Design |
| - Fast 1-24LPCB Prototype,samll-medium volume Fabrication |
| - Professional HDI PCB Production |
| - Rigid-Flex Board Manufacture |
| - SMT Assembly / PCBA Assembly |
| - PCB Parts Sourcing |
Design-parameters:
Design Delivery Time:
Design completed:
| Design completed data | |||||
| PCB Layout File | YES | Manufacturing File | YES | DXF File | YES |
| PAST File | YES | Silk File | YES | XY coordinates File | YES |
Mail Content Display :
Attached you can find the fabrication files for the ABCD single board, all the fabrication and assembly process as per the following files.The design files shall be deleted within 3 days after fabrication,so please back up the files,thank you !
--ABCD_PCB.ZIP → the pcb design files(.brd,.pcb)
--ABCD_CAM.ZIP → the file for pcb manufacturing
--ABCD_ASM.ZIP → the assembly files for pcb welding
--ABCD_SMD.ZIP → the SMT files for the SMT manufacturing
--ABCD_DXF.ZIP → the structure files for comfirming structure
--ABCD_SILK.ZIP → the silkscreen files for reference use of the assembly factory
Any questions ,please contact me ,thank you !
Hope we have a nice cooperation!
