Other Pcb & Pcba China Circuit Board Zero Pcb Board
- Category: PCB & PCBA >>>
- Supplier: Shenzhen FS Technology Co. Ltd.
Share on (1600658678851):
Product Overview
Description
Custom adaptive built-in pcb antenna omni directional wifi fpc 5g 2.4g 868mhz esp32 gsm gold plated pcb antenna pcb antenna
Products Description
SMT Lines | 7 Lines | |
Capacity | 8 Million Placements Per Day | |
Max Board Size | 680*550mm Smallest:0.25"*0.25" | |
Min Components size | 0201-54 sq.mm (0.084 sq.inch),Long Connector,CSP,BGA,QFP | |
Speed | 0.15sec/chip, 0.7sec/QFP | |
wave-Solder | Max.PCB Width:450mm | |
Min.PCB Width:unlimited | ||
Components Height:Top 120mm/Bot 15mm | ||
Metal Types:Part,Whole,Inlay,Side-step | ||
Metal Material:Copper,Aluminum | ||
Surface Finish:Plating Au,Plating Silver,Plating Sn | ||
Air Bladder Rate:less than 20% | ||
Press Range:0-50KN | ||
Max.PCB Size:800*600mm | ||
Assembly Types | SMT and Thru-hole | |
Solder Type | Water Soluble Solder Paste,Leaded and Lead-Free | |
File Formats | Bill of Materials ,Gerber Files,Pick-N-Place Files(XYRS) | |
Type of Service | Turn-Key,Partial Turn-Kye or Consignment | |
Component Packaging | Cut Tape,Tube Reels Loose,Parts | |
Turn Time | 1-15days | |
Testing | XRAY Inspection,AOI Testing ICT,Flying Probe,Burn-in,Function Test | |
