Китайский производитель OEM ODM проводной USB новый дизайн Hands Free всенаправленный настольный сканер штрих кодов
- Category: Scanners >>>
- Supplier: Shenzhen Honor Way Electronic Co. Ltd.
Share on (1600845202111):
Product Overview
Description
China Manufacturer OEM ODM Wired USB New Design Handsfree Omnidirectional Desktop Barcode Scanner
Product Description
FEATURES & BENEFITS
1. Desktop flatbed & Concise design
2. Decoding min barcode density:4mil
3. Support 1D/2D barcode on paper and screen
4. Can read color barcode
5. High speed image acquisition and decoding
6. Infrared induction trigger
Product Parameters
Item | Para.Name | Para Value |
Reading performance | Image Sensor | CMOS |
Resolution | 752 x 480,60fps | |
Decoding capacity | Support paper and screen barcodes | |
2D: QR,PDF417,Micro PDF417, Data Matrix etc. | ||
1D: UPC/EAN, Code39, interleaved 2 of 5, Code93, Code 128, CodaBar, Industry25, Matrix25 | ||
Precision | 0.1 mm(4mil)@Code 39, PCS=90% | |
Light Source | 620nm Visible Red Diode | |
View Angle | 66°(H) x50°(V) | |
Scan Angle | Rotation360°,tilt±50°,skew±60° | |
Scan speed | 280 times / sec | |
Trigger Mode | Manual / Continuous scan/ Auto Detective | |
Scan distance | 5mil: 5 to 10 cm, max 80 cm | |
Mechanical and electrical | Interface | USB, RS232,USB COM |
Working Voltage | 5VDC±10% | |
Power | Operating 1.2W(160mA@5VDC) Standby 0.2W | |
Dimensions | 140mm x75mm x80mm | |
Weight | 296g | |
Indication | LED &Buzzer | |
Environment Request | Working Tem | 0℃~ +40℃ |
Storage Tem | -20℃~ +60℃ | |
Humidity | 5%-95%(Non-condensing) | |
Ingression Protection | IP43 | |
Light level | 0~4,000 Lux, 0~100,000 Lux(sunlight) | |
Shock resistance | Designed to withstand 1.2 meters drop on concrete surface |
recommended product
business card
Company Information
Our Services
Our service and commitment
1. The MOQ can be 1pcs,customer can test it firstly.
2. Product warranty—24 months
3. Welcome customer OEM, like assembly, test, even we can help customer to find good resource in China.
4. ODM--customize hardware and appearance structure according to customer requirements
5. If you encounter any problems during the use of the product, you can directly contact us by email or telephone.
6. About the package, We will pack the smallest package for you, saving your shipping costs.
7. We have cooperated with many logistics companies so that we can choose the cheapest shipping for you.
8. How to deal with after-sales quality problems, if the product is not intentionally damaged, please send pictures
and videos that can be confirmed as product problems, we will analyze and confirm the compensation method
(for products only), we can re-send the product for free.
9. We are a legal and formal Chinese enterprise under the supervision of the China Industrial and Commercial Bureau,
the Taxation Bureau, the Customs and the Foreign Exchange Administration.We have operation rights of import and
export,and we will comply with national and international trade regulations and do legal export trade.
10. We will not arbitrarily offer high prices, deceive customers, and always hold the attitude of long-term cooperation
with customers to bring customers cost-effective products and high quality services.
