Full Digital conference speech meeting conference system with Discussion/voting sign in/desktop nameplate
- Category: >>>
- Supplier: Guangzhou DSPPA Audio Co. Ltd.
Share on (1600890285053):
Product Overview
Description
Details Images
Features
●Sensitivity: -26dBFS
●Hot Backup function.
●A single conference system can connect with up to 4096 conference units.
●As a distributed conference system with Network Transmission protocol, it provides uncompressed, high-sound-quality and easy-to-install solution.
●The simultaneous limit of speakers (1/2/3/4/5/6) setting.
●4.3" TFT true color screen/touch screen:
●The graphical interface design provides a clear view of all functions and settings, as well as basic information about the unit’s operation, and the design is beautiful and stylish;
●Touch screen handling; Machine-human interaction makes it extremely user-friendly.
●You can set the VIP delegate unit, which can be opened freely without limitation of conference mode if the total number of working microphones is less than 6, and the 32 VIP units can be set at most.
●Supporting such five conference modes as first-in-first-out, normal, voice-control, free, application modes. Up to 6 units can be on simultaneously.
●Built-in DSP digital sound processor, including low frequency cuts and equalizers.
●You can record a full Conference, either automatically or manually.
●It has a unit detection function, automatic and manual.
●Featuring timing and speech countdown reminder function. The timed speech feature can set the time of speech for the unit or turn off it, i.e free of restriction.
●Featuring turning off all wireless units by one-touch, you can modify the UHF segment radio transmit frequency.
●The host computer has an integrated camera tracking system and 6 HDMI camera interfaces for automatic camera tracking.
●Hot Backup function.
●A single conference system can connect with up to 4096 conference units.
●As a distributed conference system with Network Transmission protocol, it provides uncompressed, high-sound-quality and easy-to-install solution.
●The simultaneous limit of speakers (1/2/3/4/5/6) setting.
●4.3" TFT true color screen/touch screen:
●The graphical interface design provides a clear view of all functions and settings, as well as basic information about the unit’s operation, and the design is beautiful and stylish;
●Touch screen handling; Machine-human interaction makes it extremely user-friendly.
●You can set the VIP delegate unit, which can be opened freely without limitation of conference mode if the total number of working microphones is less than 6, and the 32 VIP units can be set at most.
●Supporting such five conference modes as first-in-first-out, normal, voice-control, free, application modes. Up to 6 units can be on simultaneously.
●Built-in DSP digital sound processor, including low frequency cuts and equalizers.
●You can record a full Conference, either automatically or manually.
●It has a unit detection function, automatic and manual.
●Featuring timing and speech countdown reminder function. The timed speech feature can set the time of speech for the unit or turn off it, i.e free of restriction.
●Featuring turning off all wireless units by one-touch, you can modify the UHF segment radio transmit frequency.
●The host computer has an integrated camera tracking system and 6 HDMI camera interfaces for automatic camera tracking.
Product Paramenters
Model | D7101 |
Line input voltage | 250 ± 50mV |
Alarm input voltage | 250 ± 50mV |
Line output voltage | 1000 ± 100mV |
Balance output voltage | 2000 ± 100mV |
Frequency response: | 30Hz-20kHz (±3dB) |
Signal-to-noise ratio | ≥ 80dB |
Harmonic distortion | ≤ 0.5% |
Maximum Output power | 90W, 4-channel network PoE+48V power supply |
Static power consumption | ≤ 30W |
UHF Frequency | 632 MHz---695 MHz |
Power switch | AC220V/50Hz/350W |
Package size(L x W x H) | 525×480×185mm |
Machine dimensions(L x W x H) | 483×385×88mm |
Gross weight | 7.8kg |
Net weight | 6.3kg |
DSPPA Solutions
Related Products
Company Introduction
FAQ
Q: Are you manufacturer or trade company? Where is your factory?
A: We are manufacturer since 1988. Our Factory address is No.1 Xiahe Road, Jianggao Town, Baiyun District, Guangzhou, Guangdong Province, China 510450
Q: I want make my own brand, is this available?
A: Certainly. We provide OEM/ODM service for you and make your own brand on the products.
Q: What’s your Minimum Order Quantity(MOQ)?
A: We have big warehouse, if the item is in stock, 1pcs is available, if we don’t have enough stock, you need to inquiry the sales
manager.
Q: What’s the payment term?
A: Usually we provide 30% as deposit and Balance before delivery, T/T is the first optional.
Q: Do you have any other payment terms?
A: We can also accept Paypal, WestUnion, Alibaba credit assurance order and so on.
Q: What kind of Certification do you have?
A: We have CE, RoHs, UL, CCC, ISO90001, ISO20000, RF, AOE, SGS and so on.
Q: How about the lead time?
A: Usually, 5 days for instock sample and 30 days for mass production, it depends.
Q: Do you have any successful case?
A: 2008 Beijing Olympic Games
Singapore Central Hospital Project
2014 Winter Olympics in Sochi, Russia
2016 G20 Hangzhou Summit
2018 Jakarta Asian Games
A: We are manufacturer since 1988. Our Factory address is No.1 Xiahe Road, Jianggao Town, Baiyun District, Guangzhou, Guangdong Province, China 510450
Q: I want make my own brand, is this available?
A: Certainly. We provide OEM/ODM service for you and make your own brand on the products.
Q: What’s your Minimum Order Quantity(MOQ)?
A: We have big warehouse, if the item is in stock, 1pcs is available, if we don’t have enough stock, you need to inquiry the sales
manager.
Q: What’s the payment term?
A: Usually we provide 30% as deposit and Balance before delivery, T/T is the first optional.
Q: Do you have any other payment terms?
A: We can also accept Paypal, WestUnion, Alibaba credit assurance order and so on.
Q: What kind of Certification do you have?
A: We have CE, RoHs, UL, CCC, ISO90001, ISO20000, RF, AOE, SGS and so on.
Q: How about the lead time?
A: Usually, 5 days for instock sample and 30 days for mass production, it depends.
Q: Do you have any successful case?
A: 2008 Beijing Olympic Games
Singapore Central Hospital Project
2014 Winter Olympics in Sochi, Russia
2016 G20 Hangzhou Summit
2018 Jakarta Asian Games
